- INTEL Core i9 14900KS 14th Generation Processor ( 6.2 GHz / 24 Cores / 32 Threads )
Description
Features of INTEL Core i9 14900KS 14th Generation Processor
Intel® Core™ i9-14900KS desktop processor. Featuring Intel® Adaptive Boost Technology, Intel® Thermal Velocity Boost, Intel® Turbo Boost Max Technology 3.0, and PCIe 5.0 & 4.0 support, DDR5 and DDR4 support, unlocked Intel® Core™ i9 desktop processors (14th Gen) are optimized for enthusiast gamers and serious creators and help deliver high performance. Compatible with Intel® 700 Series and Intel® 600 Series Chipset based motherboards. 150W Processor Base Power.
- Game without compromise. Play harder and work smarter with Intel Core 14th Gen processors
- 24 cores (8 P-cores + 16 E-cores) and 32 threads. Integrated Intel UHD Graphics 770 included
- Up to 5.9 GHz with Turbo Boost Max Technology 3.0 gives you smooth game play, high frame rates, and rapid responsiveness
- Compatible with Intel 600-series (with potential BIOS update) or 700-series chipset-based motherboards
- DDR4 and DDR5 platform support cuts your load times and gives you the space to run the most demanding games
THE WORLD’S FASTEST DESKTOP PROCESSOR
Game without compromise. Aimed at extreme gamers and enthusiasts, Intel® CoreTM i9-14900KS Processor pushes the maximum boost clock up to 6.2 GHz. Take advantage of Intel’s performance hybrid architecture designed for optimized performance in all scenarios and supercharge your CPU performance with a powerful suite of tuning and overclocking tools.
Intel® Thermal Velocity Boost
Opportunistically increases clock frequency by up to 100MHz; available if the CPU’s within temperature limits (70°C for desktops, 65°C for mobile) and turbo power budget is available.
Intel® Application Optimization
Determines and directs application resources in real time. This policy optimizes thread scheduling along with application threading for selected software titles and may improve performance for supported applications.
Intel® Extreme Tuning Utility with AI Assist
AI Assist is a preview software feature within Intel® Extreme Tuning Utility (Intel® XTU) that uses an AI (Artificial Intelligence) model to generate a proposed set of values for overclocking a system. It allows for easier overclocking as it characterizes individual system configuration.
Best-in-class Connectivity with Discrete Intel® Wi-Fi 7 (5 Gig) Support
Get ready for wired-like experiences with the extreme levels of speed, low latency, and reliability enabled by Intel® Wi-Fi 7.
PCIe 5.0 and 4.0 Support
Support for PCIe 5.0 ensures fast access to discrete graphics, storage, and peripheral devices, while support for PCIe 4.0 ensures fast access to storage and peripheral devices.
DDR5 and DDR4 Support
DDR5 delivers the latest, industry-leading innovation in memory capabilities for fast speeds, high bandwidth, and enhanced workflow productivity. DDR4 Support ensures continued support of existing memory technology and speeds.
Core and Memory Overclocking
When paired with the Intel® Z790 or Z690 chipset, processor P-cores, E-cores, graphics, and memory can be set to run at frequencies above the processor specification resulting in higher performance.
Specifications of INTEL Core i9 14900KS 14th Generation Processor
Model Number | BX8071514900KS |
Essentials | |
Product Collection | Intel® Core i9 processors (14th gen) |
Code Name | Products formerly Raptor Lake |
Vertical Segment | Desktop |
Processor Number | i9-14900KS |
Lithography | Intel 7 |
CPU Specifications | |
Total Cores | 24 |
# of Performance-cores | 8 |
# of Efficient-cores | 16 |
Total Threads | 32 |
Max Turbo Frequency | 6.2 GHz |
Intel® Thermal Velocity Boost Frequency | 6.2 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency ‡ | 5.9 GHz |
Performance-core Max Turbo Frequency | 5.7 GHz |
Efficient-core Max Turbo Frequency | 4.5 GHz |
Performance-core Base Frequency | 3.2 GHz |
Efficient-core Base Frequency | 2.4 GHz |
Cache | 36 MB Intel® Smart Cache |
Total L2 Cache | 32 MB |
Processor Base Power | 150 W |
Maximum Turbo Power | 253 W |
Supplemental Information | |
Marketing Status | Launched |
Launch Date | Q1'24 |
Embedded Options Available | No |
Use Conditions | PC/Client/Tablet |
Memory Specifications | |
Max Memory Size (dependent on memory type) | 192 GB |
Memory Types | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 89.6 GB/s |
ECC Memory Supported ‡ | Yes |
GPU Specifications | |
GPU Name‡ | Intel® UHD Graphics 770 |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 1.65 GHz |
Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
Execution Units | 32 |
Max Resolution (HDMI)‡ | 4096 x 2160 @ 60Hz |
Max Resolution (DP)‡ | 7680 x 4320 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel)‡ | 5120 x 3200 @ 120Hz |
DirectX* Support | 12 |
OpenGL* Support | 4.5 |
OpenCL* Support | 3 |
Multi-Format Codec Engines | 2 |
Intel® Quick Sync Video | Yes |
Intel® Clear Video HD Technology | Yes |
# of Displays Supported ‡ | 4 |
Device ID | 0xA780 |
Expansion Options | |
Direct Media Interface (DMI) Revision | 4 |
Max # of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations ‡ | Up to 1x16+4, 2x8+4 |
Max # of PCI Express Lanes | 20 |
Package Specifications | |
Sockets Supported | FCLGA1700 |
Max CPU Configuration | 1 |
TJUNCTION | 100°C |
Package Size | 45.0 mm x 37.5 mm |
Max Operating Temperature | 100 °C |
Advanced Technologies | |
Intel® Gaussian & Neural Accelerator | 3 |
Intel® Thread Director | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Adaptive Boost Technology | Yes |
Intel® Thermal Velocity Boost | Yes |
Intel® Turbo Boost Max Technology 3.0 ‡ | Yes |
Intel® Turbo Boost Technology ‡ | 2 |
Intel® Hyper-Threading Technology ‡ | Yes |
Intel® 64 ‡ | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
Security & Reliability | |
Intel vPro® Eligibility ‡ | Intel vPro® Enterprise, Intel vPro® Essentials, Intel vPro® Platform |
Intel® Threat Detection Technology (TDT) | Yes |
Intel® Active Management Technology (AMT) ‡ | Yes |
Intel® Standard Manageability (ISM) ‡ | Yes |
Intel® Remote Platform Erase (RPE) ‡ | Yes |
Intel® One-Click Recovery ‡ | Yes |
Intel® Hardware Shield Eligibility ‡ | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® Total Memory Encryption - Multi Key | Yes |
Intel® AES New Instructions | Yes |
Secure Key | Yes |
Intel® OS Guard | Yes |
Intel® Trusted Execution Technology ‡ | Yes |
Execute Disable Bit ‡ | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡ | Yes |
Intel® Virtualization Technology (VT-x) ‡ | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
Warranty | 3 Years |
Note | *** Image use for reference only *** Features, Price, Specifications are subject to change without notice. |
