- FANATEC CSL DD QR2 Wheel Base
Description
Features of FANATEC CSL DD QR2 Wheel Base
Push the limits using an exceptional Direct Drive Wheel Base in a compact design. Now including QR2, you'll enjoy even more precision and detailed force feedback.
CSL DD. NOW WITH QR2.
FANATEC® DIRECT-DRIVE TECHNOLOGY.
PLUG AND PLAY.
TORQUE TO THE HANDS.
The 100% custom motor was developed in Germany specifically for sim racing. It delivers sensational performance thanks to patented FluxBarrier technology, communicating the nuances of force feedback detail to your hands with remarkable clarity.
EFFICIENT AND RESPONSIVE.
The efficiency of the CSL DD motor technology means dynamic force-feedback performance is contained in a small footprint. This is also the first industrial motor to feature a carbon fibre composite motor shaft, which increases responsiveness and acceleration significantly due to low rotational masses.
UP TO 8 NM OF TORQUE.
Standard peak torque is 5 Nm, with the Boost Kit 180 (sold separately) unlocking the full 8 Nm. This high level of torque can be sustained without the need for active cooling, with the extruded and CNC-machined aluminium casing acting as the structural chassis as well as the heatsink.
MOTORSPORT-DERIVED QUICK RELEASE SYSTEM.
The new QR2 quick release delivers rock-solid performance at the highest level. The shape of the coupling was developed for use in real-world motorsport, originally used in the 2022 BMW M4 GT3 race car.
EVERYTHING JUST CLICKS.
Steering Wheel attachment has never been easier. Simply bring the wheel towards the base and push to fit - no need to touch the quick release.
HOT-SWAP.
The carbon fibre-reinforced polyamide construction allows for fast and secure switching of steering wheels. Hot-swap between different wheel designs without needing to restart the sim or your Wheel Base.
Special Notes
-
Not suitable for children. The fast movements of the steering wheel and strong torque can be dangerous. Please read the safety instructions.
- The QR2 Lite Base-Side (Type-C) included with the CSL DD QR2 is compatible with all versions of the QR2 Wheel-Side (Lite, Regular, Pro) and does not cause any torque restriction, even with the Boost Kit 180.
- To enable features such as Steering Wheel LEDs in some titles, it may be necessary to switch the CSL DD to Compatibility Mode. This can also help with titles not working in standard PC mode. Check the Quick Guide for details.
Specifications of FANATEC CSL DD QR2 Wheel Base
| Model | CSL_DD_QR2L_90_EU |
| Drive System | Direct-Drive |
| Force Feedback | Instant, detailed force feedback |
| Peak Torque | 5 Nm |
| Optional Upgrade | Boost Kit 180 |
| Maximum Torque with Boost Kit | 8 Nm |
| Motor Technology | FluxBarrier technology |
| SDK Support | Full Fanatec SDK support |
| Standard Tuning Menu | Supported |
| Advanced Tuning Menu | Supported |
| Position Sensor | High-resolution contactless Hall-position-sensor |
| Steering Axis Material | Carbon fibre-enhanced composite |
| Cooling System | Fanless |
| Housing Material | Aluminium with composite end caps |
| Heat Dissipation | Passive heat sink |
| Rotation | 2520 degrees |
| Rotation Adjustment | Electronically limited and adjustable |
| Slip Ring System | Cable-free power and data transfer |
| Quick Release System | QR2 quick release system |
| Quick Release Type | Motorsport-derived |
| Quick Release Construction | Carbon fibre-reinforced polyamide |
| Quick Release Feature | Exchangeable |
| Mounting System | T-nut rail system on sides and bottom |
| Table Clamp | Optional |
| Supported Table Thickness | 5 to 60 mm |
| Power Port | Yes |
| Console/PC Connection | USB-C |
| Data Port | Fanatec DataPort-C |
| Shifter Ports | Shifter 1 and Shifter 2 |
| Shifter 2 Support | Sequential only |
| Pedal Port | Yes |
| Handbrake Port | Yes |
| Front-Mounted Inserts | Threaded inserts for Fanatec accessories |
| Compatiblity | The CSL DD QR2 Wheel Base is compatible with: All Fanatec Steering Wheels (with QR2 Lite Wheel-Side, QR2 Wheel-Side, or QR2 Pro Wheel-Side) All Fanatec Pedals (adapter cables might be required on pedals without RJ12 connection) ClubSport Shifter (including ClubSport Static Shifter Paddles) ClubSport Handbrake (all versions) All Fanatec Cockpits CSL DD Table Clamp ClubSport DD Table Clamp ClubSport Table Clamp V2 Boost Kit 180 Podium Mounting Brackets (the CSL DD includes M6 T-nuts for side-mounting; the Podium Mounting Brackets require the use of M6 bolts and washers) |
| Platforms | PC: The CSL DD QR2 Wheel Base is compatible with PC when combined with a Fanatec Steering Wheel. Check the individual Steering Wheel product pages for Wheel Base compatibility. Xbox®: The CSL DD QR2 Wheel Base becomes compatible with Xbox One® and Xbox Series X|S when used with any Fanatec Xbox-licensed Steering Wheel. PlayStation®: The CSL DD QR2 Wheel Base is not compatible with any PlayStation® console and cannot be upgraded to achieve compatibility. |
| What's Included | CSL DD Wheel Base QR2 Lite Base-Side (Type-C) preinstalled 90W power supply (regional)* 4x T-nuts for rail mount system USB cable (Type-C to Type-A) Quick Guide *If you select the Boost Kit 180 (180W power supply), the standard power supply is not included. |
| Warranty | 3-Year Warranty |
