- TPLink TL-WR820N 300 Mbps Multi-Mode Wi-Fi Router
Description
Features of TPLink TL-WR820N 300 Mbps Multi-Mode Wi-Fi Router
- 300 Mbps Wi-Fi speed is ideal for daily tasks including browsing, emailing, and video streaming
- IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
- Guest Network provides separate access for guests while securing the host network
- Parental Controls manage when and how connected devices can access the internet
- SPI firewall and wireless encryption protect your home network
- Compatible with IPv6 (Internet Protocol version 6)
Specifications of TPLink TL-WR820N 300 Mbps Multi-Mode Wi-Fi Router
WIRELESS | |
Standards |
Wi-Fi 4 IEEE 802.11n/b/g 2.4 GHz |
WiFi Speeds |
N300 2.4 GHz: 300 Mbps (802.11n) |
WiFi Range | 2 Bedroom Houses2× Fixed Antennas |
WiFi Capacity | Legacy |
Working Modes |
Router Mode Access Point Mode Range Extender Mode WISP Mode |
HARDWARE | |
Processor | Single-Core CPU |
Ethernet Ports |
1× 10/100 Mbps WAN Port 2× 10/100 Mbps LAN Ports |
Buttons | Reset Button |
Power | 5 V ⎓ 0.6 A |
SECURITY | |
WiFi Encryption |
WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) |
Network Security |
SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
Guest Network | 1× 2.4 GHz Guest Network |
SOFTWARE | |
Protocols |
IPv4 IPv6 |
Parental Controls |
URL Filtering Time Controls |
WAN Types |
Dynamic IP Static IP PPPoE PPTP L2TP |
Quality of Service | QoS by Device |
NAT Forwarding |
Port Forwarding Port Triggering DMZ UPnP |
IPTV |
IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP |
Address Reservation DHCP Client List Server |
DDNS |
NO-IP DynDNS |
Management | Tether App |
OTHER | |
System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
Certifications | FCC, CE, RoHS |
Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
TEST DATA | |
WiFi Transmission Power |
CE: <20dBm(2.4GHz) FCC: <30dBm |
WiFi Reception Sensitivity |
270M: -70dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -87dBm@8% PER 6M: -90dBm@10% PER 1M: -98dBm@8% PER |
PHYSICAL | |
Dimensions (W×D×H) |
4.5 × 4.2 × 1.0 in (115 × 106.7 × 24.3 mm) |
Package Contents |
Wi-Fi Router TL-WR820N Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
