- THERMALTAKE CTE C700 ARGB ATX Mid Tower Cabinet ( Snow White )
Description
Features of THERMALTAKE CTE C700 ARGB ATX Mid Tower Cabinet ( Snow White )
The THERMALTAKE CTE C700 TG ARGB Snow, a specially designed E-ATX mid tower chassis from the new CTE form factor series, was engineered to provide optimal thermal efficiency to ensure that critical components of your build are provided with adequate cooling. To achieve this the CTE C700 TG ARGB Snow can support up to a 420mm AIO radiator not only at the front but also at the rear of the chassis. Three 140mm CT140 ARGB fans are pre-installed.
The CTE Form Factor Designed by Thermaltake, stands for Centralized Thermal Efficiency, and is focused around providing high level thermal performance to critical components. The design utilizes a 90-degree rotation of the motherboard providing more efficient airflow pathways.
Since the CPU location has been moved much closer to the front panel and the graphics card moved closer towards the rear panel, independent cold air induction is given for thermal dissipation of the CPU and graphics card respectively. This overall approach has allowed CTE to provide better and more efficient intake airflow through the placement of main components and cooling, as well as optimization to heat extraction from the system
Since the CPU location has been moved much closer to the front panel and the graphics card moved closer towards the rear panel, independent cold air induction is given for thermal dissipation of the CPU and graphics card respectively. This overall approach has allowed CTE to provide better and more efficient intake airflow through the placement of main components and cooling, as well as optimization to heat extraction from the system
Since the CPU location of the CTE C700 has been moved much closer to the front panel and the graphics card moved closer towards the rear panel, independent cold air induction is given for thermal dissipation of the CPU and graphics card respectively.
This overall approach has allowed Thermaltake Cabinet CTE C700 to provide better and more efficient intake airflow through the placement of main components and cooling, as well as optimization to heat extraction from the system.
The CTE C700 TG ARGB Snow, a specially designed white cabinet pc from the new CTE form factor series, was engineered to provide optimal thermal efficiency to ensure that critical components of your build are provided with adequate cooling. To achieve this the CTE C700 can support up to a 420mm AIO radiator not only at the front but also at the rear of the case. It comes with three 140mm CT140 ARGB fans pre-installed and it can support up to a 420mm AIO radiator at the front and at the rear of the chassis. Its dual-chamber design allows users to showcase key components and provides ample space for superior cooling solutions, with the ability to accommodate up to twelve 120mm fans (eleven 140mm fans) inside the case thanks to the front, bottom, rear and right fan brackets, as well as the top fan vent. It also features many nice details such as two different PCI-E slots, removable filters, a pump and reservoir bracket and Velcro straps for easy cable management. Whether you are a PC enthusiast or looking for a custom liquid cooling case, get ready to be amazed by the CTE C700 TG ARGB pc cabinet
Specification of THERMALTAKE CTE C700 ARGB ATX Mid Tower Cabinet ( Snow White )
P/N | CA-1X7-00F6WN-01 |
Series | CTE |
CASE TYPE | Mid Tower |
Dimension (H x W x D) | 566.5 x 327.6 x 505.5 mm (22.3 x 12.9 x 19.9 inch) |
NET WEIGHT | 15.8 kg / 34.83 lbs. |
PANEL | 4mm Tempered Glass x 2 |
Color | White |
MATERIAL | SPCC / ABS |
COOLING SYSTEM | Front(intake): 140 x 140 x 25 mm CT140 ARGB white fan (1500rpm, 30.5 dBA) x 1 Top(exhaust): 140 x 140 x 25 mm CT140 ARGB white fan (1500rpm, 30.5 dBA) x 1 Rear(intake): 140 x 140 x 25 mm CT140 ARGB white fan (1500rpm, 30.5 dBA) x 1 |
Drive Bays | 7 x 3.5” or 6 x 2.5” |
EXPANSION SLOTS | 7 |
MOTHERBOARDS | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13” (E-ATX) |
I/O Port | USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1 |
PSU | Standard PS2 PSU (optional) |
FAN SUPPORT | Front: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm 2 x 200mm, 1 x 200mm Top: 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Right: 1 x 120mm, 1 x 140mm Rear: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm Bottom: 3 x 120mm, 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm |
RADIATOR SUPPORT | Front: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm Rear: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm Bottom: 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 280mm, 1 x 140mm |
CLEARANCE | CPU cooler max height: 190mm VGA max length: 327mm (With radiator) 410mm (Without radiator) PSU max length: 220mm |
