SUPER FLOWER Leadex III Gold Up 850W 80 + Gold Fully Modular ATX 3.1 Power Supply ( 850W ) ( Black )

Features of SUPER FLOWER Leadex III Gold Up 850W 80 + Gold Fully Modular ATX 3.1 Power Supply

LEADEX III GE is fully compatible with Intel ATX 3.1 Specifications, supporting up to 200% power excursion. HCS terminals & Dual 8-pin sockets on the modular panel to 12+4 pin socket on GPU side, safer design to avoid high angle bending issue. Modern Design to meet the latest safety & PC requirement with IEC/EN 62368 & ALPM mode.

140mm F.D.B Fan: Unique 7-blade design for high airflow and more stable cooling system and provides accurate RPM thus minimizing the noise (dBA).

• Copper shaft around the bearing which provides stability and durability during operation thus better heat dissipation and longer life span.
•  New patented technology of Buckle (20+4) Pin connector  (Patent No.: Taiwan M563575 ; China 7566010,USA)
• Innovative Design for gaming System & PSU protection
  1. DC output +12V/ +5V/ +3.3V remain stable
  2. Dynamic loading (Transient response) improvement on +12V/+5V/+3.3V
  3. +12V Output With Exceptional Low Ripple Measurements
  4. Low Output Voltage Ripple
•  ECO-design
    1. Auto & ECO Fan control
    2. High efficiency on all rails, including 5VSB
•  100% Fully Modular With All Ultra Flexible Ribbon Cables For Easy Cable Management.
• 80 PLUS® Gold Certified,87% 90% 87% Efficiency At 20% 50% 100% Rated Load.
• Japanese Main Capacitor
• Full Range Auto Voltage Detection Design 100V~240V (Active PFC)
• Comply With ATX 12V v3.1, EPS 12V v2.92 Specification.
• Comply With Energy Star Standard & EuP (Energy Using Products) Regulation
• Over Voltage Protection / Over Current Protection / Over Power Protection / Short Circuit Protection / Under Voltage Protection / Over Temperature Protection / No Load Operation / Surge & Inrush Protection
• Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards (Haswell ready)
• Support NVIDIA® SLI™ & ATI CrossFireX™ High Performance Graphic Card
• More than 2,000 times On/Off test
• Lead-free Green Materials with RoHS / WEEE Compliance
• Perfect For Professional & High Performance Gaming System
• PCI-E (6+2) Pin Connector For High-End Graphic Card Requirement.

Specification of SUPER FLOWER Leadex III Gold Up 850W 80 + Gold Fully Modular ATX 3.1 Power Supply
