- SILVERSTONE LD03-AF ITX Mini Tower Cabinet (Black)
Description
Features of SILVERSTONE LD03-AF
For excellent cooling Silverstone cabinet LD03-AF features a 1 x 120mm fan on top and a 1 x 120mm fan on the bottom. Compatibility is an essential feature. SilverStone LD03-AF Cabinet is compatible with Mini-ITX motherboard & SFX PSU. SilverStone LD03-AF Cabinet is fully equipped with quick access to all the removable filters. The fantastic SilverStone LD03-AF Cabinet supports high-end graphic cards too. These filters help to catch dust and also you can clean it easily. The dimensions of SilverStone LD03-AF Cabinet are 265mm (W) x 414mm (H) x 230mm (D). The amusing SilverStone LD03-AF Cabinet comes with a warranty of a whole year.
- Tinted tempered glass panels for reserved or expressive styling
- Air inlet cutout on left tempered glass for increased GPU cooling capacity
- Supermini footprint design with no cables and vents on four sides for excellent integration into any computing environment
- Includes two 120mm fans for excellent airflow and supports up to two 120mm radiators
- Supports 2.5" and 3.5" drives
- Mini-DTX / Mini-ITX motherboard & SFX / SFX-L PSU compatible
- Supports full-size CPU cooler and graphics cards
Enhanced GPU cooling efficiency
Retaining the great CPU and system cooling performance of the original, the LD03-AF adds an air inlet cutout to the left tempered glass panel for enhanced air cooling capacity to most high-end graphics cards on the market.
Stack effect design
With motherboard rotated 90 degrees, cool air can flow smoothly from the bottom up for the most efficient heat dissipation to all important heat-generating components.
Combining advanced engineering with precision manufacturing
Exclusive tool-less buckle design makes front panel and side panels removal easier than ever. Exterior also looks sharper and cleaner as a result of no exposed screws.
Modest size, extraordinary accommodation
SILVERSTONE LD03-AF’s generous interior space means there is nearly no limit in what you can build into it.
Modest size, extraordinary accommodation II
Supports various high-end graphics cards
Quick access to all removable filters
Filters are made of fine nylon mesh to catch dust effectively without airflow performance penalty. They are easy to remove to help you better maintain your system.
Specifications of SILVERSTONE LD03-AF
Model No. | SST-LD03B-AF (Black, Airflow version) |
Material | Tempered glass panels, steel body |
Motherboard | Mini-DTX , Mini-ITX |
Drive bay | |
External | -- |
Internal | 3.5" x 1 (compatible with 2.5"), 2.5" x 1 |
Cooling system | |
Front | -- |
Rear | -- |
Side | -- |
Top | 1 x 120mm fan (120mm fan x 1 included) |
Bottom | 1 x 120mm fan (120mm fan x 1 included) |
Internal | -- |
Expansion slot | 2 |
Front I/O port |
USB Type-C x 1 USB 3.0 x 1 Audio x 1 MIC x 1 |
Power supply | SFX & SFX-L |
Expansion card | Compatible up to 12.1" (309mm) long, width restriction 6.59" (167mm)* |
Limitation of CPU cooler | 190mm |
Net weight | 5.22kg |
Dimension |
265mm (W) x 414mm (H) x 230mm (D), 25.2 Liters 10.43" (W) x 16.3" (H) x 9.06" (D), 25.2 Liters |
Warranty | 1 Year |
Note | ***Features, Price and Specifications are subject to change without notice. |
