- SEAGATE Skyhawk Lite 2TB Desktop HDD
Description
Features of SEAGATE Skyhawk Lite 2TB Desktop HDD
- Image Perfect firmware is designed to ensure seamless video footage capture in 24×7 surveillance workloads that record video from 64 HD cameras
- Skyhawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options, RAID Rapid Rebuild is the latest feature, which provides 3× faster volume rebuilds over traditional RAID rebuilds
- RV sensors built in allow drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed
- ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage
- Up to 14 TB 3 or over 9,345 hours 4 of HD video storage support an increased number of HD cameras and allows longer data retention periods
- Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions, tarnish-resistant components help protect drive from environmental elements, increasing field reliability
- For performance-related issues in Seagate Internal SSD/ Internal HDD, contact Seagate Customer Care Toll free# 0008004401392 In case you are not satisfied the resolution provided the brand, please reach back to Amazon Customer Service for next steps.
- 1M hour MTBF - designed for high write duty cycle across SEAGATE SkyHawk Lite
- ATA AV Command support - streaming video command support across SkyHawk Lite
- Best-in-class acoustic performance means virtually silent operation
- Built-in error recovery for non-stop video streaming
- Compliant with RoHS requirements in China and Europe
- Full-track multiple-sector transfer capability without local processor intervention
- Idle3 power mode support
- Low activity power
- Low-RPM spindle speed
Specifications of SEAGATE Skyhawk Lite 2TB Desktop HDD
| Model Number | ST2000VX007 |
| Formatted capacity (512 bytes/sector) | 2000GB (2TB) |
| Guaranteed sectors | 3,907,029,168 |
| Heads | 2 |
| Disks | 1 |
| Bytes per sector (emulated at 512-byte sectors) | 4096 (physical) |
| Default sectors per track | 63 |
| Default read/write heads | 16 |
| Default cylinders | 16,383 |
| Recording density (max) | 2294 kB/in |
| Track density (avg) | 540 ktracks/in |
| Areal density (avg) | 1203 Gb/in2 |
| SATA interface transfer rate | 600 MB/s |
| Maximum data transfer rate | 180 MB/s |
| ATA data-transfer modes supported |
PIO modes: 0 to 4 Multiword DMA modes: 0 to 2 Ultra DMA modes 0 to 6 |
| Height (max) | 20.20mm / 0.795 in |
| Width (max) | 101.6mm (± 0.25) / 4.0 in (± 0.010) |
| Length (max) | 146.99mm / 5.787 in |
| Average latency | 6.0 ms |
| Standby to ready (typ) | 9.0s |
| Startup current (typical) 12V | 1.1A |
| Voltage tolerance (including noise) | 5V ±5% / 12V ±10% |
| Non-Operating (Ambient °C) | –40° to 70° |
| Operating ambient temperature (min °C) | 0° |
| Operating temperature (drive case max °C) | 70°† |
| Temperature gradient |
20°C per hour max (operating) 30°C per hour max (non-operating) |
| Relative humidity |
5% to 90% (operating) 5% to 95% (non-operating) |
| Relative humidity gradient (max) | 30% per hour |
| Wet bulb temperature (max) |
30°C max (operating) 40°C max (non-operating) |
| Altitude, operating |
–304m to 3048m (–1000 ft to 10,000 ft) |
|
Altitude, non-operating (below mean sea level, max) |
–304m to12,192m (–1000 ft to 40,000 ft) |
| Operational shock (max) | 80 Gs (read) / 70 Gs (write) at 2ms |
| Non-operational shock (max) | 350 Gs at 2ms |
| Vibration, operating |
10Hz to 22Hz: 0.25 Gs, Limited displacement 22Hz to 350Hz: 0.50 Gs 350Hz to 500Hz: 0.25 Gs |
| Vibration, non-operating |
5Hz to 22Hz: 3.0 Gs 22Hz to 350Hz: 3.0 Gs 350Hz to 500Hz: 3.0 Gs |
| Idle*** |
1.8 bels (typical) 1.9 bels (max) |
| Seek |
2.0 bels (typical) 2.1 bels (max) |
| Non-recoverable read errors | 1 per 1014 bits read |
| Load/unload cycles | 300,000 at 25°C, 50% rel. humidity |
|
Supports hotplug operation per the Serial ATA Revision 3.2 specification |
Yes |
| Warranty | 3 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
