- SAMSUNG 860 EVO 2TB 2.5 SATA SATA 3 Solid State Drive (SSD)
Description
Features of SAMSUNG 860 EVO 2TB 2.5 SATA SATA 3 Solid State Drive (SSD)
Samsung 860 EVO 2TB SATA 2.5" SSD is one of the newest addition to the Samsung mainstream desktop and laptop SSD’s. The Samsung 860 EVO 2TB SATA 2.5" SSD comes with the latest high-quality V-NAND from Samsung providing great speeds. Coming in the smaller 2.5-inch form factor and having a low weight of less than 60 grams makes it compatible to use with most mainstream high-end desktops and laptops for higher storage capacity and with lower space requirement while providing much higher speeds during file transfer and renders. Operating between 0℃ and 70℃ and an MTBF of 1.5 trillion hours, it comes as a suitable choice both for Highend desktops and laptop users whose work focuses from 4k Video rendering to making 3D data that is used by the latest application.
The 860 EVO has a sequential read/write of 550 MB/s/520 MB/s. The 860 EVO supports the 6Gb/s interface and older 3Gb/s and 1.5Gb/s interfaces. The SSD consumes an average of 3W with a maximum of 4W during heavy usage. Using the refined ECC algorithm and using the new Samsung MJX controller it provides higher speeds. The 860 EVO also comes with the Samsung Magician software for monitoring the SSD’s health and performance, providing performance benchmark tools Data security and Protect data can be done by selecting security options. The 860 EVO even supports AES 256-bit hardware-based encryption and is compliant with TCG Opal and IEEE 1667 providing data security and data reliability. The Samsung 860 EVO also comes with 5 years or 1200TBW of limited warranty.
The SSD to trust
The newest edition to the world’s best-selling* SATA SSD series, the Samsung 860 EVO. Specially designed for mainstream PCs and laptops, with the latest V-NAND and a robust algorithm-based controller, this fast and reliable SSD comes in a wide range of compatible form factors and capacities.
Enhanced performance
Speeds are more consistent, even with heavy workloads and multi-tasks. The 860 EVO performs at sequential writes up to 520 MB/s* with Intelligent TurboWrite technology, and sequential reads up to 550 MB/s. The TurboWrite buffer size* is upgraded from 12 GB to 78 GB for faster file transfer.
Boosted endurance
Safely store and render large sized 4K videos and 3D data used by the latest applications, up to 8x higher TBW (Terabytes Written)* than the previous 850 EVO. The latest V-NAND technology gives you up to 2,400 TBW, or is backed by a 5-year limited warranty.*
Smart compatibility
Benefit from faster, more fluid communication with your host system. The refined ECC* algorithm and a new MJX controller generate higher speeds, and the improved queued trim enhances Linux compatibility. Our advanced engineering makes the 860 EVO more compatible with your computing system.
Multi form factors
Whatever size your computer needs, there is an 860 EVO for you. Choose among the 2.5-inch size for desktop PCs and laptops, and the SATA-based M.2 (2280) or the mSATA for ultra-slim computing devices.
Specifications of SAMSUNG 860 EVO 2TB 2.5 SATA SATA 3 Solid State Drive (SSD)
Application | Client PCs |
Capacity | 2TB |
Form Factor | 2.5 inch |
Interface | SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface |
Dimension (WxHxD) | 100 X 69.85 X 6.8 (mm) |
Weight | Max 51.0 g Weight |
NAND Type | Samsung V-NAND 3bit MLC |
Controller | Samsung MJX Controller |
Cache Memory | Samsung 2GB Low Power DDR4 SDRAM |
TRIM Support | TRIM Supported |
S.M.A.R.T Support | S.M.A.R.T Supported |
GC (Garbage Collection) | Auto Garbage Collection Algorithm |
Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
WWN Support | World Wide Name supported |
Device Sleep Mode Support | Yes |
Sequential Read | Up to 550 MB/s Sequential Read |
Sequential Write | Up to 520 MB/s Sequential Write |
Random Read (4KB, QD32) | Up to 98,000 IOPS Random Read |
Random Write (4KB, QD32) | Up to 90,000 IOPS Random Write |
Random Read (4KB, QD1) | Up to 10,000 IOPS Random Read |
Random Write (4KB, QD1) | Up to 42,000 IOPS Random Write |
Power Consumption | Average: 3.0 W *Maximum: 4.0 W |
Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
Operating Temperature | 0 - 70℃Operating Temperature |
Shock | 1,500 G & 0.5 ms (Half sine) |
Management SW | Magician Software for SSD management |
Warranty | 5 Years |
Note | ***Features, Price and Specifications are subject to change without notice. |
