- SAMSUNG 860 EVO 250GB 2.5 SATA SATA 3 Solid State Drive (SSD)
Description
Features of SAMSUNG 860 EVO 250GB 2.5 SATA SATA 3 Solid State Drive (SSD)
Samsung 860 EVO 250GB SATA 2.5" SSD is designed for mainstream desktop and laptops. The Samsung 860 EVO 250GB SATA 2.5" SSD comes with the latest V-NAND and a robust algorithm-based controller. The 860 EVO is a fast and reliable SSD from Samsung. The 860 EVO uses a SATA III connection to store and move data across devices. The SSD uses intelligent turbo write with sequential reads up to 550 MB/S (or 98K IOPS) and sequential write speeds up to 520 MB/S(or 90K IOPS). The 860 EVO has a turbo write buffer of 12GB. It uses the standard SATA III 6Gb/s and is also compatible with the SATA III 3Gb/s and SATA III 1Gb/s standards. You can store and render large size 4k videos and 3D data that is used by the latest applications.
The latest V-NAND technology gives up to 150TBW(Terabytes Written). The refined ECC(Error Correction Code) algorithm and a new MJX controller generate higher speeds which makes the 860 EVO more compatible with computing systems. The Samsung Magician software can be used to monitor the health of the SSD and track various features with a simple and easy to use interface. The 860 EVO SSD also supports 256-bit hardware-based encryption and is compliant with TCL opal and IEEE 1667. The dimensions(WxHxD) of the SSD is 100.00 x 69.85 x 6.80 (mm) and the max weight is 62 grams. The 860 EVO comes with a 5-year warranty or 150 TBW along with reliable tech support from Samsung.
The SSD to trust
The newest edition to the world’s best-selling* SATA SSD series, the Samsung 860 EVO. Specially designed for mainstream PCs and laptops, with the latest V-NAND and a robust algorithm-based controller, this fast and reliable SSD comes in a wide range of compatible form factors and capacities.
Enhanced performance
Speeds are more consistent, even with heavy workloads and multi-tasks. The 860 EVO performs at sequential writes up to 520 MB/s* with Intelligent TurboWrite technology, and sequential reads up to 550 MB/s. The TurboWrite buffer size* is upgraded from 12 GB to 78 GB for faster file transfer.
Boosted endurance
Safely store and render large sized 4K videos and 3D data used by the latest applications, up to 8x higher TBW (Terabytes Written)* than the previous 850 EVO. The latest V-NAND technology gives you up to 2,400 TBW, or is backed by a 5-year limited warranty.*
Smart compatibility
Benefit from faster, more fluid communication with your host system. The refined ECC* algorithm and a new MJX controller generate higher speeds, and the improved queued trim enhances Linux compatibility. Our advanced engineering makes the 860 EVO more compatible with your computing system.
Multi form factors
Whatever size your computer needs, there is an 860 EVO for you. Choose among the 2.5-inch size for desktop PCs and laptops, and the SATA-based M.2 (2280) or the mSATA for ultra-slim computing devices.
Specifications of SAMSUNG 860 EVO 250GB 2.5 SATA SATA 3 Solid State Drive (SSD)
Application | Client PCs |
Capacity | 250 GB |
Form Factor | 2.5 inch |
Interface | SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface |
Dimension (WxHxD) | 100 X 69.85 X 6.8 (mm) |
Weight | Max 51.0 g Weight |
NAND Type | Samsung V-NAND 3bit MLC |
Controller | Samsung MJX Controller |
Cache Memory | Samsung 512 MB Low Power DDR4 SDRAM |
TRIM Support | TRIM Supported |
S.M.A.R.T Support | S.M.A.R.T Supported |
GC (Garbage Collection) | Auto Garbage Collection Algorithm |
Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
WWN Support | World Wide Name supported |
Device Sleep Mode Support | Yes |
Sequential Read | Up to 550 MB/s Sequential Read |
Sequential Write | Up to 520 MB/s Sequential Write |
Random Read (4KB, QD32) | Up to 98,000 IOPS Random Read |
Random Write (4KB, QD32) | Up to 90,000 IOPS Random Write |
Random Read (4KB, QD1) | Up to 10,000 IOPS Random Read |
Random Write (4KB, QD1) | Up to 42,000 IOPS Random Write |
Power Consumption | Average: 3.0 W *Maximum: 4.0 W |
Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
Operating Temperature | 0 - 70℃Operating Temperature |
Shock | 1,500 G & 0.5 ms (Half sine) |
Management SW | Magician Software for SSD management |
Warranty | 5 Years |
Note | ***Features, Price and Specifications are subject to change without notice. |
