- PHANTEKS XT View E-ATX DRGB Mid Tower Cabinet (Black)
Description
Features of PHANTEKS XT View E-ATX DRGB Mid Tower (Black)
With new hardware releases demanding more cooling capacity and internal space, the PHANTEKS XT View E-ATX DRGB cabinets are designed to deliver just that. And it delivers extremely good value. The length and width of the chassis easily fit even the largest graphics cards with space to spare for cable management. Cooling has been optimized with up to 9x 120 mm fan locations, support for 140 mm fans and dedicated radiator space in the top of the chassis.
Phanteks CPU Case XT-Series further innovates to bring support for the latest mainboards that host hidden connectors at the rear to unlock that zero-cable setup. The graphics card also benefits from 3x 120 mm fan locations on the mid-plate that provides direct cooling. Best cpu case with fan at affordable prices at Elitehubs!
COMPUTING WITH A VIEW
-
Near-seamless glass panels.
-
Plenty of space for the most powerful graphics cards.
-
Mesh all-around for high performance cooling.
COOL AND POWERFUL
-
Dedicated top 360 radiator space in the top.
-
Triple 120mm positions on the midplate for direct GPU cooling.
-
Supports a total of 9x 120mm fan locations.
BUILD FOR THE FUTURE
-
UNLOCK THE ZERO-CABLE SETUP
Mainboards with hidden connectors on the rear-side are fully supported by the XT Pro chassis. -
Support for MSI Project Zero mainboards.
-
Support for ASUS BTF mainboards.
PACKED WITH VALUE
-
Powerful and cool with 3x D-RGB 120mm fans build in.
-
USB-C 3.2 Gen2 for ultra-fast data transfers.
INTEGRATED D-RGB LIGHTING
-
- Refined D-RGB lighting effects that just work, no software required
-
Built-in LED strip along the power supply cover.
-
Optionally sync with motherboard and software
MULTIPLE STORAGE OPTIONS
-
Configuration 01
5x 2.5″ + 1x 3.5″ -
Configuration 02
3x 2.5″ + 2x 3.5″
Specifications of PHANTEKS XT View E-ATX DRGB Mid Tower (Black)
ProductDimension(DxWxH) | 440x230x500mm |
FormFactor | Mid Tower |
Motherboard Support | ATX,Micro-ATX,Mini-IT,E-ATX(280mm without GPU support bracket) |
Materials | Steel Chassis (Tempered Glass) |
Front lO | IxUSB-C3.2 GEN 2 2xUSB3.0 Microphone/HeadphoneCombo ResetButton PowerButton D-RGB Color button D-RGB Mode button |
Connectors | Power Switch Reset Switch HD-audio USB3.0 USB3.2 GEN 2 Type-E D-RGB expansion D-RGB Motherboard |
Expansion | |
PCI Slots | 7 |
Internal 3.5" Bay | 2(2x included) |
Internal 2.5" Bay | 5 (5 x included) |
Fans & Radiators | |
Top Fan | 3 x 120mm/2 x 140mm |
Right Side Fan | 2x 120mm |
Rear Fan | 1x l20mm/ 1x 140mm |
Midplate Fan | 3 x 120mm |
Top Radiator | up to 360 |
Right Side Radiator | up to 240 (onlywithVerticalGPU} |
Rear Radiator | 120 |
Clearances | |
GPU Length | 415 mm |
GPU Width | 184 mm |
CPU Cooler Height | 184 mm |
Power Supply | 270 mm |
Top 360 radiator | 415 x 138 x 60 mm |
Side 240 radiator | 305 x 120 x 62mm (only with Vertcal GPU) |
Rear Radiator | 120 |
Warranty | 5 Years |
Note | *** Features, Price, Specifications are subject to change without notice. |
