- NZXT H6 Flow ATX Mid Tower Cabinet (Black)
Description
Features Of NZXT H6 Flow ATX Mid Tower Cabinet (Black)
Experience peak performance within an innovative compact dual-chamber. Prioritizing GPU cooling, NZXT H6 Flow ATX Cabinet panoramic glass showcases the interior while freeing up space for improved airflow.
Wraparound glass panels with a seamless edge provides an unobstructed view of the inside to highlight key components.
Compact dual-chamber design of nzxt cpu case improves overall thermal performance and creates a clean, uncrowded aesthetic.
Includes three pre-installed 120mm fans positioned at an ideal angle for superb out-of-the-box cooling.
The top and side panels feature an airflow-optimized perforation pattern to enhance overall performance and filter dust.
An intuitive cable management system simplifies the build process by using wide channels and straps.
Tool-free access to the top and side panels makes upgrading quick and convenient.
Top panel supports radiators up to 360mm in length. Up to 365mm GPU and 200mm PSU clearance
Compact Dual-Chamber
Improves cooling performance and creates an uncrowded aesthetic.
Out-of-the-Box Cooling
3 x 120mm fans are angled for optimal out-of-the-box cooling.
High Performance Airflow
Perforation pattern on the panels is optimized for maximum airflow.
Cable Management
Easily manage cables with the wide channels and included straps.
Tool-Free Entry
Access the top and side panels without tools for quick upgrades.
Spacious Support
Up to a 360mm radiator in the top and clearance for a 365mm GPU.
Get the affordable cpu case with fan in the huge variety with us!
Specifications Of NZXT H6 Flow ATX Mid Tower Cabinet (Black)
Model Number | CC-H61FB-01 |
Key Specs | |
Motherboard Support | ATX, Micro-ATX, Mini-ITX |
Enclosure Type | Mid-Tower |
Case Material | SGCC Steel, Ultra-Clear Tempered Glass, Dark Tinted Tempered Glass (Black SKU only) |
Drive Bays | |
2.5" | 2 |
3.5" | 1 |
Dimensions | |
Height (with feet) | 435 mm / 17.13 in |
Width | 287 mm / 11.3 in |
Depth | 415 mm / 16.34 in |
Weight | 9.4 kg |
Fan Support | |
Front-Right | 3 x 120 mm (3 x F120Q included) |
Top | 3 x 120 mm / 2 x 140 mm |
Bottom | 2 x 140 mm |
Rear | 1 x 120 mm |
Filters | High-Performance Mesh |
Compatibility & Clearance | |
CPU Cooler Height | 163 mm / 6.42 in |
GPU Length | 365 mm / 14.37 in |
PSU Length | 200 mm / 7.87 in |
Cable Management | 91 mm / 3.58 in |
Top Radiator | 30 mm / 1.18 in |
Radiator Support | |
Top | Up to 360 mm |
Rear | Up to 120 mm |
Front I/O Ports | |
USB 3.2 Gen 1 Type-A | 2 |
USB 3.2 Gen 2 Type-C | 1 |
Headset Audio Jack | 1 |
Fan Specs | |
Model | F120Q Airflow Fan (Case Version) |
Speed | 1200 ± 240RPM |
Airflow | 62.18 CFM |
Static | 1.05 mm - H2O |
Noise | 25.1 dBA |
Fan Connector | 3-pin |
Expansion Slots | |
Standard | 7 |
Vertical | 0 |
Warranty | 2 Years |
Note | *** Features, Price, Specifications are subject to change without notice. |
Reviews ( 0 )
Frequently asked questions
1. Does the NZXT H6 Flow come with fans?
Yes, NZXT H6 Flow has three pre-installed 120mm fans. These are placed strategically on the front and side for that instant airflow. The installation is meant to provide maximum cooling from the box so that users can proceed with building their system without having to go out first to buy extra fans. The included fans help to make the case live up to its role of being one that is designed to provide efficient thermal performance, one that is among the design aspects of the H6 Flow.
2. How to remove NZXT H6 Flow front panel?
Removal of the front panel for the NZXT H6 Flow is simple. Start by tugging on the bottom of the panel. The panel is secured by snap clips, so a soft but forceful tug will dislodge it. After removing the bottom, lift and pull the panel off. No equipment is utilized in performing this, and it is easy to open the front fan mounts to clean them or include additional fans. It is easy to maintain and customize with this design.
3. Does NZXT H6 Flow have good airflow?
Yes, the NZXT H6 Flow is engineered with improved airflow in mind. Its perforated panels and thoughtfully placed fan mounts allow for maximum airflow. The case itself is designed for direct airflow to large components, allowing for efficient cooling. The pre-installed fans also guarantee maximum airflow. Reviews and user feedback always mention the H6 Flow's capacity to keep temperatures low, even under heavy usage. This makes it a high-performance build favorite.
4. Is a NZXT H6 Flow case good?
The NZXT H6 Flow is a solid case in general, especially for those who prioritize airflow. Its design prioritizes effective cooling, which is the key to high-performance systems. The case provides plenty of room for components and has easy cable management, making it friendly to a clean and organized build. The design also plays a significant factor with its slim thin profile and side panel tempered glass. H6 Flow would suit anyone who wishes for the optimal mix of both performance and look. 5. Is NZXT H6 Flow an ARGB?
5. Is the NZXT H6 Flow an ARGB?
The NZXT H6 Flow in itself is not a natively an ARGB case. Pre-installed on the case are standard fans and not ARGB fans, neither do they incorporate ARGB lights. The case is, nevertheless, ARGB component compatible. Users can add their own ARGB fans and lighting strips themselves to customize the look of the case. Case design offers suitable visibility of the installed lighting because of the side panel made from tempered glass.
6. What is the price of NZXT H6 Flow?
NZXT H6 Flow price is dependent on seller and location. It tends to be in the middle range of ATX mid-tower enclosures. You can find it at ₹12,595 on EliteHubs. Note that prices tend to change with offers, promotions, and stock status.
7. Are NZXT H6 Flow fans quiet?
The NZXT H6 Flow comes with pre-installed fans that are optimized to provide maximum airflow and noise. Although they cool well enough, they are not silent fans. The noise is acceptable to most users, particularly when the system is under a moderate load. It might increase under heavy load. Another alternative for the user who wants quiet performance is to replace the stock fans with quieter ones.
8. What is the maximum length of a NZXT H6 Flow GPU?
NZXT H6 Flow supports GPUs with a maximum length of 365mm. This is generous clearance, allowing for most high-end available graphics cards in the market to be installed. The users are always encouraged to check the specific size of their GPU to ensure compatibility. The case design has space for big GPUs, and therefore it is best suited for gaming and content creation computers.
9. Which NZXT H6 Flow is best?
The best NZXT H6 Flow is primarily referring to the basic white or black model. The primary difference between the two models is the color. The design and the features are consistent across all designs of the H6 Flow. The individual's preference for color is the main aspect. If you're seeking special editions or an alternative color, they are available, however, the basic black or white is the most commonly used and widely regarded as the most effective in terms of cost to performance.
