Description
NZXT H510 ELITE MID-TOWER CABINET WITH TEMPERED GLASS AND RGB LED STRIP (White BLACK)
Now create your dream PC by choosing from presets or custom controls for your RGB lighting and fans with the help of an intuitive NZXT CAM application to monitor and control your build. Tired of never-ending cable management? A cable routing kit consisting of pre-installed channels and straps has been designed by us for simple and easy wiring. For optimal internal airflow, a set of two Aer F120mm fans are included. Along with removable filters for the front panel and PSU intakes. We have designed a removable bracket for radiators up to 280mm which helps to simplify the installation of closed-loop or custom-loop water cooling. Now you can install your GPU vertically with the built-in mounting bracket.
Features:
- Two tempered glass panels top off your build, perfectly showcasing your RGB build. We’ve included two Aer RGB 2 fans and an RGB LED strip to get you started.
- The H510 Elite features a removable radiator mounting bracket, simple-to-use SSD trays, and a patented cable management system for a smarter, easier build experience. The new Smart Device 2 includes two HUE 2 RGB lighting channels, and three fan channels that support 0dB modes for voltage-regulated or PWM fans.
- The USB 3.1 Gen 2-compatible USB-C connector on the front panel makes it easier than ever to connect smartphones, high-speed external storage, and the latest peripherals to your PC.
- The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass panels all showcase your stunning build.
- Use the intuitive NZXT CAM application to monitor and control your build, choosing from presets or custom controls for your RGB lighting and fans to create your dream PC.
Specifications:
| Model Number | CA-H510E-B1 |
| Dimensions |
W: 210mm H: 435mm D: 428mm (without feet) W: 210mm H: 460mm D: 428mm (with feet) |
| Material(s) | SGCC Steel and Tempered Glass |
| Motherboard Support | ATX |
| I/O Ports |
Type-C : 1x USB 3.1 Gen 2 Type-A : 1x USB 3.1 Gen 1 1x Headset Audio Jack |
| Filters | All Air Intakes |
| Expansion Slots | 7 |
| Smart Device |
3x Fan channels with Max 10W per channel output* 2x RGB LED channels, each support up to 4x HUE 2 addressable LED strips or 5x Aer RGB 2 fans Built-in noise detection module *Note : If a splitter is used, fan control is regulated depending on the fan connected to the 4-pin port . Do not use low-noise adapters. |
| System Requirements |
PC with open internal USB 2.0 port and Windows® 10 operating system recommended. Internet connection is needed to download CAM. Some CAM features require Internet access, a valid email address and acceptance of our current Terms of Service. |
| LED Strips |
1 integrated ARGB LED strip No additional strips included. |
| Drive Bays |
2.5”: 2 1 3.5”: 2 1 |
| Radiator Support |
Front: 2x 140 or 2x 120mm with Pull Rear: 1x 120mm |
| Fan Support |
Front: 2x 120/ 2x 140mm (2x AER RGB 2 140mm included) Top: 1x 120mm/ 1x 140mm (1x AER F140 Case Version Included) Rear: 1x 120mm (1x AER F120 Case Version Included) |
| Fan Specs |
Aer RGB 2 (140mm) Speed: 500-1,500 RPM Airflow: 30.39 - 91.19 CFM Noise: 22 - 33 dBA Air Pressure: 0.17 – 1.52mm-H2O Bearing: Fluid Dynamic Bearing Fan Connector 4-Pin PWM |
| Clearance |
Cable Management: 19-23mm GPU Clearance: Up to 368.5mm Vertical GPU Mount Clearance: 40.64mm CPU Cooler: Up to 165mm Front Radiator: 60mm Rear Radiator: 60mm Reservoir & Pump: Up to 180mm (Along cable bar), Up to 86mm (Along bottom panel) |
| Warranty | 2 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
