- NZXT H5 Elite ATX Mid Tower Cabinet (White)
Description
Features Of NZXT H5 Elite ATX Mid Tower Cabinet (White)
The H5 Elite features a tempered glass front panel and built-in RGB functionality to showcase various lighting components. With optimized thermal performance and intuitive cable management, NZXT H5 Elite ATX Cabinet is an ideal chassis for most builds.
- Pre-installed fan on bottom inside panel is angled to cool GPU
- Tempered glass front panel and built-in RGB controller
- Perforated top panel provides optimal ventilation
- Intuitive cable management system with wide channels, hooks, & straps
- Tool-less access to front & side panels
- Front panel supports 2 x 140mm fans or 280mm radiator
- Top panel supports up to 2 x 120mm fans or 240mm radiator
- Includes two pre-installed F140 RGB fans & one F120Q fan
Fan Capacity
nzxt cpu case fan mounts offer space for two 140mm fans on the front panel and two 120mm fans on the top panel.
- Top: 2x 120mm
- Front: 2x 140mm / 2x 120mm
- Rear: 1x 120mm
- Bottom: 1x 120mm
Radiator Capacity
The top panel offers space for a 240mm radiator and the front panel provides room for a 280mm radiator.
Get the affordable cpu case with fan with the huge variety with us!
Specifications Of NZXT H5 Elite ATX Mid Tower Cabinet (White)
Key Specs | |
Motherboard Support | Mini-ITX, Micro-ATX, ATX, and EATX (Up to 272mm) |
Enclosure Type | Mid-Tower |
Case Material | SGCC Steel, Tempered Glass |
Fan Support | |
Front | 2 x F Series RGB 140mm (Case Version) included |
Top | 2 x 120mm |
Rear | 1 x 120mm |
Bottom | 1 x F Series Quiet 120mm (Case Version) included |
Filters | All Air Intakes |
Dimensions | |
Height | 464 mm (With Feet) |
Width | 227 mm |
Depth | 446 mm |
Weight | 8.1 kg |
Radiator Support | |
Front | Up to 280mm |
Top | Up to 240mm |
Rear | Up to 120mm |
Compatibility & Clearance | |
Max CPU Cooler Clearance | Up to 165mm |
Max GPU Clearance | Up to 365mm |
Front Radiator Clearance | 45mm |
Cable Management | Up to 23mm |
Fan Specs | |
Model | F140 RGB Fan |
Speed | 500 - 1800 RPM |
Airflow | 24.85 - 89.48 CFM |
Static Pressure | 0.94 - 3.39 mm-H2O |
Noise | 20 - 32.5 dBA |
Fan Connector | 4-pin |
Front I/O Ports | |
USB 3.2 Gen 1 Type-A | 1 |
USB 3.2 Gen 2 Type-C | 1 |
Headset Audio Jack | 1 |
Fan Specs | |
Model | F120Q Airflow Fan (Case Version) |
Speed | 1200 ± 240 RPM |
Airflow | 62.18 CFM |
Static Pressure | 1.05 mm-H2O |
Noise | 25.1 dBA |
Fan Connector | 3-pin |
Included Accessories | |
Installation screws | 1 |
Cable ties | 10 |
RGB Lighting Controller | NZXT RGB Connector: 3 (Support up to 120 LEDs) |
Expansion Slots | |
Standard | 7 |
Drive Bays | |
2.5" | 1+1 |
3.5" | 1 |
Warranty | 2 Years |
Note |
*** Features, Price, Specifications are subject to change without notice.
|
