Description
Feature of MSI MAG PANO 100R PZ ATX Mid Tower Cabinet (White)
Chamfering Technique
Each piece of 4 mm tempered glass is cut at an angle to minimize every edge gap to make case appearance look more beautiful.
HARDWARE COMPATIBILITY
MSI Cabinet MAG PANO 100R PZ cases offers extensive support for the installation of your hardware components.
BACK-CONNECT MOTHERBOARD SUPPORTED
Supporting ATX and Micro-ATX back-connect PROJECT ZERO motherboards enables easy installation without the worry of forgetting to connect cables
DUAL CHAMBER
Large cable management space to reduce cable routing complexity, ensuring sufficient space for cable organization.
MULTI-FUNCTION STORAGE BRACKET
The multi-function storage bracket with swinging door serves as a convenient tool for SSD installation and cover the messy cables, maintaining a clean and aesthetic appearance in the main chamber.
DUST FILTER
The case equipped with removable filters on three sides, easy for cleaning. This ensures improved airflow and protects internal components from dust accumulation.
Removable panel design
The front, side and top panels are tool-free to remove, when installing side fans and radiators, there are no obstacles to hinder your progress.
MSI MAG PANO 100R ATX Cabinet has Pre-installed with 3 x ARGB reverse blade fans at the side and 1 x ARGB fan at the rear, ensuring optimal airflow while maintaining a pleasing and clean appearance.
Decorated with a metal nameplate, enhancing the case's quality and highlighting the segment identity.
Equiped with ARGB lighting board, fully supported by MSI mystic light with MSI motherboard.
Best cpu case with fan at affordable prices at Elitehubs!
Specifications of MSI MAG PANO 100R PZ ATX Mid Tower Cabinet (White)
Product Name | MSI MAG PANO 100R PZ |
Case Form Factor | Mid Tower |
Motherboard Form Factor Support |
Regular: ATX / Micro-ATX / Mini-ITX Back-connect: ATX / Micro-ATX |
I/O Ports |
1 x USB 20Gbps Type-C 2 x USB 5Gbps Type-A 1 x Audio-Out / Mic-in 1 x LED Switch Button 1 x Power Button |
Drive Mount Support |
3 x 2.5” 2 x 2.5”/3.5” combo |
Expansion Slots | 8 |
Maximum GPU Length | 380 mm / 14.96 inches |
Maximum CPU Cooler Height | 166 mm / 6.54 inches |
Power Supply Support | ATX |
Maximum PSU Length | 200 mm / 7.87 inches |
Fan Size Support |
Top: 3 x 120 mm / 3 x 140 mm Front: NA Rear: 1 x 120 mm Side: 3 x 120 mm / 2 x 140 mm Bottom: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm |
Pre-installed Fan Size |
Side: 3 x 120 mm Rear: 1 x 120 mm |
Pre-installed Fan Type |
Side: 3 x ARGB Reverse-blade Rear: 1 x ARGB |
Radiator Size Support |
Top: 120 / 240 / 360 mm Front: NA Rear: 120 mm Side: 120 / 240 / 360 mm Bottom: 120 / 240 / 360 mm |
Dimensions (DxWxH) | 518.7 x 290 x 482 mm / 20.42 x 11.42 x 18.98 inches |
