- LIAN LI O11 Dynamic EVO EATX Mid Tower Cabinet (Grey)
Description
Features of LIAN LI O11 Dynamic EVO EATX (Grey)
Keep cool with the LIAN LI O11 Dynamic EVO EATX Cabinet (Grey) all-new design and express the preferable configuration.
- Mid-tower chassis with two modes: Normal Mode/ Reverse Mode
- Feature multi-directional power button and movable IO module
- Front and side tempered glass panels for components and RGB display
- Supports up to 3x 360 radiators and a maximum of 10 fans
- Offers 9 storage drives mounting space
- Dual-chamber layout with hooks friendly cable management compartment
- Number of PSU supported : 2
- Five optional accessories: Vertical GPU Kit / Upright GPU Kit / Additional I/O kit / Front Mesh Kit / Top I/O Kit
BUILD WITH THE FINEST MATERIALS
With only a few steps, the O11D EVO can be flipped in reverse mode to experience a seamless front and side tempered glass showroom view on the right side of the chassis.
THE HARBOR GREY
Presenting an all-new color option with grey coated aluminum and darker tinted tempered glass panels.
● Grey Coated Mesh Panel
● Dark Tinted Tempered Glass
● Black Interior
● Aluminium with harbor grey powder coating
● Light Grey Rubber Grommets
● Black Feet
VERSATILE ORIENTATION
With only a few steps, the O11D EVO can be flipped in reverse mode to experience a seamless front and side tempered glass showroom view on the right side of the chassis.
EXQUISITE, YET FUNCTIONAL
Following the style of the O11 Dynamic series, the aluminum panels feature an updated fine mesh which provides an optimal ratio of airflow and dust filtering.
INNOVATIVE AND FLEXIBLE CONFIGURATION
Featuring a modular design, the O11D EVO offers many configuration potentials when making use of optional kits, both for air cooling and water cooling.
AIR COOLING
UNRESTRICTED AIRFLOW
The more direct the airflow, the better the cooling performance. Thanks to the upright GPU kit and the front mesh kit, which makes the addition of 3 extra fans at the front possible, the O11D EVO can provide powerful and direct airflow to the GPU and the CPU.
AIR COOLING
UPGRADED VERTICAL GPUAIRFLOW
lian li cabinet upgraded vertical GPU kit provides more room for bottom-mounted fans and radiators to increase the cooling capability and efficiency of the O11D EVO. Users can either mount the GPU vertically at the lower position which provides 50mm of clearance at the bottom of the chassis, or the upper position for 90.5mm of clearance.
CUSTOM WATER COOLING
SUPREME THERMAL CONTROL
With the upright GPU kit, users can move their water-cooled GPU next to the motherboard. This opens up the main chamber of the chassis, allowing simpler and more efficient tube runs to reach the components, and creating a restriction-free chimney-style airflow that allows the top and bottom radiators to perform more effectively.
SPACIOUS COOLING SUPPORT
The O11D EVO features sufficient space to accommodate 3x 360mm radiators, and up to 10 fans.
MASSIVE STORAGE CAPACITY
Multiple easily accessible storage mounting points are provided to support up to 9x SSDs or 6x HDDs + 3x SSDs.
CLEAN LOOK
The O11D EVO keeps the front panel as clean as possible with a multi-directional power button that can be pressed from both the front and the side of the chassis.
PERSONALIZED ARGB LIGHTING STRIP
The front panel LED strip features 7 built-in lighting effects which can be controlled via the M button. An 8th mode is available to enable motherboard software synchronization or L-Connect control.
FRIENDLY BUILDING PROCESS
EASILY REMOVABLE PANELS
The new mechanism to mount the side panels simplifies the process to reach the interior of the case by eliminating the need to first open the top panel.
STRUGGLE-FREE FAN BRACKETS
While each fan bracket features a quick-release design, they can be fixed to the chassis via a straightforward process.
EFFORTLESS CABLE MANAGEMENT
The O11D EVO optimizes the user’s ability to cable manage their system with a dual-chamber design and a removable bracket.
RELOCATABLE I/O PORT
At the bottom of the chassis, the I/O module can be relocated to 3 different locations without the use of any tools
OPTIONAL ACCESSORIES
ADDITIONAL I/O PORTS
Double the number of USB ports for a total of 4 × USB 3.0 Type-A and 2 × USB 3.1 Type-C with the additional accessory.
POTENTIAL FOR DUAL PSU
The drive cage can be removed to make place for a second PSU, or be switched to a lower position.
ANTI-SAG BRACKET FOR PERFECTLY HORIZONTAL GPU
The GPU anti-sag bracket is included for displaying hardware through the seamless front and side tempered glass panels.
IN COLLABORATION WITH DER8AUER
In continuation of the O11D family, LIAN LI has collaborated with Der8auer and the community to finalize the O11D EVO design. Thanks to his contribution, a LIAN LI badge with De8auer’s name is provided. Users can place it on the cable management bar in their desired orientation.
Best cpu case gaming at affordable prices at Elitehubs!
Specifications of LIAN LI O11 Dynamic EVO EATX (Grey)
PRODUCT NAME | O11D EVO |
MODEL | O11DEX , O11DEW, O11DEG |
COLOR | Black, White, Harbor Grey |
DIMENSION | (D)465mm × (W)285mm × (H)459mm |
MATERIAL |
4mm Aluminum 4mm Tempered Glass 1mm Steel Structure |
MOTHERBOARD SUPPORT | E-ATX (width: under 280mm)/ATX /M-ATX/ITX |
PSU SUPPORT | 220mm |
FAN SUPPORT |
Top: 120mm × 3 or 140mm × 2 Side: 120mm × 3 or 140mm × 2 Bottom: 120mm × 3 or 140mm × 2 Rear: 120mm × 1 On Drive Cage: 60mm × 1 |
RADIATOR SUPPORT |
Top: 360mm × 1 or 280mm × 1 *Total max thickness: 87.5mm Side: 360mm × 1 or 280mm × 1 *Inner scenario total max thickness: 83mm(120mm fan on top and bottom) 63mm(140mm fan on top and bottom) *Outer scenario total max. thickness: 120mm(120mm fan on top and bottom) 100mm(140mm fan on top and bottom) Bottom: 360mm × 1 *Total max thickness: 87.5mm |
DRIVE SUPPORT |
Bottom:2.5” SSD × 4 or 3.5” HDD × 2 Side:2.5” SSD × 4 or 3.5” HDD × 2 Drive Cage:2.5” SSD × 3 or 3.5” HDD × 2 + 2.5” SSD × 1 Cable Management Bar:2.5” SSD × 2 *Only 9 sets of 2.5” SSD mounting pads are provided |
GPU LENGTH CLEARANCE | 422 mm |
CPU HEIGHT CLEARANCE | 167 mm |
EXPANSION SLOTS | 8 |
I/O PORTS |
2 × USB 3.0 1 × USB 3.1 TYPE-C, 1 × HD AUDIO/ MIC LED Color and Mode button Reset Button Power Button |
