- INTEL Core i9 12900F 12th Generation Processor ( 5.1 GHz / 16 Cores / 24Threads )
Description
Features of INTEL Core i9 12900F 12th Generation Processor
Power up your productivity, gaming, and content-creation experiences by installing the Intel Core i9-12900F 2.4 GHz 16-Core LGA 1700 Processor into your desktop computer system. Built using a Hybrid Core architecture with the Intel 7 process, this 12th generation desktop processor's 16 cores combine the performance of eight Efficient cores and eight 2.4 GHz Performance cores. The low-voltage Efficient cores handle background tasks for multitasking while the Performance cores provide speed for demanding applications and games.
The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time to maximize performance. Additionally, this processor has a 5.1 GHz Turbo Boost Max 3.0 frequency with 30MB of cache for fast and reliable performance. The Core i9-12900F also includes support for PCI Express 5.0 and dual-channel DDR5 memory at 4800 MHz to help run and multitask a variety of demanding applications.
The Core i9-12900F does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. An Intel Laminar RH1 thermal solution is included. The processor is compatible with Intel LGA 1700 socket motherboards and is backed by a 3-year warranty.
Hybrid Core Design
Background tasks are handled by the processor's Efficient cores for multitasking while the Performance cores provide the speed to handle high-end games and demanding applications.
Intel Thread Director
The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 24 threads are assigned to the right core at the right time.
- Series i9 12th generation
- CORES 16 Cores
- THREADS 8 Threads
- Socket LGA1700
- SPEED 2.4 GHz
- SPEED (TURBO) 5.1 GHz
- CACHE 30 MB
- MAX MEMORY SUPPORT 128 GB
- INTEGRATED GRAPHICS No
- INCLUDED CPU COOLER No
- UNLOCKED No
- TDP 65 W
- WARRANTY* 3 Years
Get the best intel Processor at lowest price from us today!
Specifications of INTEL Core i9 12900F 12th Generation Processor
Essentials | |
Product Collection | 12th Generation Intel® Core™ i9 Processors |
Code Name | Products formerly Alder Lake |
Vertical Segment | Desktop |
Processor Number | i9-12900F |
CPU Specifications | |
Total Cores | 8 |
of Efficient-cores | 8 |
Total Threads | 24 |
Max Turbo Frequency | 5.10 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency | 5.10 GHz |
Performance-core Max Turbo Frequency | 5.00 GHz |
Efficient-core Max Turbo Frequency | 3.80 GHz |
Performance-core Base Frequency | 2.40 GHz |
Efficient-core Base Frequency | 1.80 GHz |
Cache | 30 MB Intel® Smart Cache |
Total L2 Cache | 14 MB |
Processor Base Power | 65 W |
Maximum Turbo Power | 202 W |
Supplemental Information | |
Embedded Options Available | Embedded Options Available |
Memory Specifications | |
Max Memory Size (dependent on memory type | 128 GB |
Memory Types | Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
Max of Memory Channels | 2 |
Max Memory Bandwidth | 76.8 GB/s |
Expansion Options | |
Direct Media Interface (DMI) Revision | 4 |
Max of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations | Up to 1x16+4, 2x8+4 |
Max of PCI Express Lanes | 20 |
Package Specifications | |
Sockets Supported | FCLGA1700 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2020C |
TJUNCTION | 100°C |
Advanced Technologies | |
Intel® Gaussian & Neural Accelerator | 3 |
Intel® Thread Director | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Optane™ Memory Supported | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Max Technology 3.0 | Yes |
Intel® Turbo Boost Technology | 2 |
Intel® Hyper-Threading Technology | Yes |
Intel® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD | Yes |
Security & Reliability | |
Intel® Standard Manageability (ISM) ‡ | Yes |
Intel® AES New Instructions | Yes |
Secure Key | Yes |
Intel® OS Guard | Yes |
Execute Disable Bit ‡ | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® Virtualization Technology (VT-x) | Yes; |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
Warranty | 3-Years |
Note |
*** Features, Price, Specifications are subject to change without notice.
|
