- INTEL Core i7 13700K 13th Generation Processor ( 5.4 GHz / 16 Cores / 24 Threads )
Description
Features Of INTEL Core I7 13700K 13th Generation Processor
- Power up your productivity, gaming, and content creation with the Intel Core i7 13700K 3.4 GHz 16-Core LGA 1700 Processor.
- This 13th generation desktop processor builds upon the Hybrid Core architecture and Intel i7 process by fitting 16 cores— four more than the previous generation— onto a single processor while still fitting the LGA 1700 socket.
- Designed to provide high performance, the Intel Core i7 13700K Processor features eight low-voltage Efficient-cores that handle background tasks for multitasking.
- While the eight 3.4 GHz Performance-cores provide speed for demanding applications and games.
- The built-in Intel Thread Director in the Intel Core i7 13700K Processor ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.
- With 30MB of cache and a 5.4 GHz Turbo Boost Max 3.0 frequency, this processor is made to handle intense workloads.
- You can also overclock this processor for even greater performance.
- The Intel Core i7 13700K Processor also supports PCI Express 5.0 and dual-channel DDR5 ECC memory at 5600 MHz.
- The Intel Core i7 13700K Processor features integrated Intel UHD 770 Graphics.
Hybrid Core Design
Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor’s Efficient-cores for multitasking.
Intel Thread Director
The Intel Thread Director is built into the CPU’s cores, working with the operating system to ensure each of the 24 threads are assigned to the right core at the right time.
PCIe 4.0 & 5.0
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Integrated Graphics
Driven by Intel Xe architecture, the integrated Intel UHD 770 Graphics delivers fast, rich 3D performance for high-quality visuals with support for either one 7680 x 4320 resolution 8K monitor or up to four 3840 x 2160 resolution 4K displays with high-dynamic range.
Gaussian & Neural Accelerator 3.0
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Intel Deep Learning Boost
Accelerates AI inference to improve performance for deep learning workloads.
With the Intel Core i7 13700K Processor you can also attain the Intel Core i7-13700KF Processor.
- 16 Cores & 24 Threads
- 3.4 GHz P-Core Clock Speed
- 5.4 GHz Maximum Turbo Frequency
- LGA 1700 Socket
- 30MB Cache Memory
- Dual-Channel DDR5-5600 Memory
- Hybrid Core Architecture
- Unlocked for Overclocking
- 13th Generation (Raptor Lake)
Specifications Of INTEL Core I7 13700K 13th Generation Processor
Total Cores | 16 |
of Performance-cores | 8 |
of Efficient-cores | 8 |
Total Threads | 24 |
Max Turbo Frequency | 5.40 GHz |
Intel Turbo Boost Max Technology 3.0 Frequency | 5.40 GHz |
Performance-core Max Turbo Frequency | 5.30 GHz |
Efficient-core Max Turbo Frequency | 4.20 GHz |
Performance-core Base Frequency | 3.40 GHz |
Efficient-core Base Frequency | 2.50 GHz |
Cache | 30 MB |
Total L2 Cache | 24 MB |
Processor Base Power | 125 W |
Maximum Turbo Power | 253 W |
Supplemental Information | |
Embedded Options Available | No |
Memory Specifications | |
Max Memory Size | 128 GB |
Memory Types | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 89.6 GB/s |
ECC Memory Supported | Yes |
Processor Graphics | |
Processor Graphics | Intel® UHD Graphics 770 |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 1.60 GHz |
Graphics Output |
eDP 1.4b DP 1.4a HDMI 2.1 |
Execution Units | 32 |
Max Resolution (HDMI) | 4096 x 2160 @ 60Hz |
Max Resolution (DP) | 7680 x 4320 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel) | 5120 x 3200 @ 120Hz |
DirectX* Support | 12 |
OpenGL* Support | 4.5 |
OpenCL* Support | 3 |
Multi-Format Codec Engines | 2 |
Intel® Quick Sync Video | Yes |
Intel® Clear Video HD Technology | Yes |
of Displays Supported | 4 |
Device ID | 0xA780 |
Expansion Options | |
Direct Media Interface (DMI) Revision | 4 |
Max # of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations |
Up to 1x16+4 2x8+4 |
Max # of PCI Express Lanes | 20 |
Package Specifications | |
Sockets Supported | FCLGA1700 |
Max CPU Configuration | 1 |
TJUNCTION | 100°C |
Advanced Technologies | |
Intel® Gaussian & Neural Accelerator | 3 |
Intel® Thread Director | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Max Technology 3.0 | Yes |
Intel® Turbo Boost Technology | 2 |
Intel® Hyper-Threading Technology | Yes |
Intel® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions |
Intel SSE4.1 Intel SSE4.2 Intel AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
Security & Reliability | |
Intel® Standard Manageability (ISM) ‡ | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® AES New Instructions | Yes |
Secure Key | Yes |
Intel® OS Guard | Yes |
Intel® Trusted Execution Technology | Yes |
Execute Disable Bit | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
Warranty | 3 Years |
Note | *** Features, Price, Specifications are subject to change without notice. |
