- INTEL Core i7 12700K 12th Generation Processor ( 5 GHz / 12 Cores / 20 Threads )
Description
Features Of INTEL Core I7 12700K 12th Generation Processor
Power up your productivity, gaming, and content creation experiences by installing the Intel Core i7-12700K 3.6 GHz 12-Core LGA 1700 Processor into your desktop computer system. Built using a Hybrid Core architecture with the Intel 7 process, this 12th generation desktop processor’s 12 cores combine the performance of four Efficient-cores and eight 3.6 GHz Performance-cores. The low-voltage Efficient-cores handle background tasks for multitasking while the Performance-cores provide speed for demanding applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time to maximize performance. Additionally, this processor has a 5 GHz Turbo Boost Max 3.0 frequency with 25MB of cache for fast and reliable performance. The Intel Core i7 12700K Processor also includes support for up to PCI Express 5.0 and dual-channel DDR5 memory at 4800 MHz to help run and multitask a variety of demanding applications. You can overclock this processor for even greater performance.
The intel core i7 features integrated Intel UHD 770 Graphics. Please note that a thermal solution NOT is included. The processor is compatible with Intel LGA 1700 socket motherboards and is backed by a 3-year warranty.
- Hybrid Core Design
- Background tasks are handled by the processor’s Efficient-cores for multitasking while the Performance-cores provide the speed to handle high-end games and demanding applications.
- Intel Thread Director
- The Intel Thread Director is built into the CPU’s cores, working with the operating system to ensure each of the 20 threads are assigned to the right core at the right time.
- PCIe 4.0 & 5.0
- This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
- Integrated Graphics
- Driven by Intel Xe architecture, the integrated Intel UHD 770 Graphics delivers fast, rich 3D performance for high-quality visuals with support for either one 7680 x 4320 resolution 8K monitor or up to four 3840 x 2160 resolution 4K displays with high-dynamic range.
- Intel Deep Learning Boost
- Accelerates AI inference to improve performance for deep learning workloads.
- Gaussian & Neural Accelerator 3.0
- Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Get the best intel processors list at lowest price from us today!
Specifications Of INTEL Core I7 12700K 11th Generation Processor
Product Collection | 12th Generation Intel® Core™ i7 Processors |
Code Name | Products formerly Alder Lake |
Vertical Segment | Desktop |
Processor Number | i7-12700K |
Status | Launched |
Lithography | Intel 7 |
Use Conditions | PC/Client/Tablet |
Total Cores | 12 |
# of Performance-cores | 8 |
# of Efficient-cores | 4 |
Total Threads | 20 |
Max Turbo Frequency | 5.00 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency | 5.00 GHz |
Performance-core Max Turbo Frequency | 4.90 GHz |
Efficient-core Max Turbo Frequency | 3.80 GHz |
Performance-core Base Frequency | 3.60 GHz |
Efficient-core Base Frequency | 2.70 GHz |
Cache | 25 MB Intel® Smart Cache |
Total L2 Cache | 12 MB |
Processor Base Power | 125 W |
Maximum Turbo Power | 190 W |
Embedded Options Available | No |
Max Memory Size (dependent on memory type) | 128 GB |
Memory Types |
Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 76.8 GB/s |
Processor Graphics | Intel® UHD Graphics 770 |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 1.50 GHz |
Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
Execution Units | 32 |
Max Resolution (HDMI)‡ | 4096 x 2160 @ 60Hz |
Max Resolution (DP)‡ | 7680 x 4320 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel)‡ | 5120 x 3200 @ 120Hz |
DirectX* Support | 12 |
OpenGL* Support | 4.5 |
Multi-Format Codec Engines | 2 |
Intel® Quick Sync Video | Yes |
Intel® Clear Video HD Technology | Yes |
# of Displays Supported ‡ | 4 |
Device ID | 0x4680 |
OpenCL* Support | 2.1 |
Direct Media Interface (DMI) Revision | 4 |
Max # of DMI Lanes | 8 |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations ‡ | Up to 1x16+4, 2x8+4 |
Max # of PCI Express Lanes | 20 |
Sockets Supported | FCLGA1700 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2020A |
TJUNCTION | 100°C |
Package Size | 45.0 mm x 37.5 mm |
Intel® Gaussian & Neural Accelerator | 3 |
Intel® Thread Director | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
Intel® Optane™ Memory Supported | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Max Technology 3.0 | Yes |
Intel® Turbo Boost Technology | 2 |
Intel® Hyper-Threading Technology | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
Intel® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
Intel® AES New Instruction | Yes |
Secure Key | Yes |
Intel® OS Guard | Yes |
Execute Disable Bit | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Warranty | 3 Years |
Note | *** Features, Price, Specifications are subject to change without notice. |
