- INTEL Core i7 10700KF 10th Generation Processor ( 5.1 GHz / 8 Cores / 16 Threads )
Description
Features of INTEL Core i7 10700KF 10th Generation Processor
The Intel Core i7-10700KF is a desktop processor with 8 cores, launched in April 2020. It is part of the Core i7 lineup, using the Comet Lake architecture with Socket 1200. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 16 threads. Core i7-10700KF has 16 MB of L3 cache and operates at 3.8 GHz by default, but can boost up to 5.1 GHz, depending on the workload.
Intel is building the Intel Core i7 10700KF Processor on a 14 nm production process, the transistor count is unknown. You may freely adjust the unlocked multiplier on Core i7-10700KF, which simplifies overclocking greatly, as you can easily dial in any overclocking frequency.
With a TDP of 125 W, the Core i7-10700KF consumes a lot of power, so good cooling is definitely needed. Intel's processor supports DDR4 memory with a dual-channel interface. The highest officially supported memory speed is 2933 MT/s, but with overclocking (and the right memory modules) you can go even higher. For communication with other components in the machine, Core i7-10700KF uses a PCI-Express Gen 3 connection.
This processor does not have integrated graphics, you will need a separate graphics card.
Hardware virtualization is available on the intel core i7, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware.
Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.
- SeriesCore i7 (10th Gen)
- CORES8 Cores
- THREADS16 Threads
- SocketLGA1200
- SPEED3.8 GHz
- SPEED (TURBO)5.1 GHz
- CACHE16 MB
- MAX MEMORY SUPPORT128 GB
- INTEGRATED GRAPHICSNo
- INCLUDED CPU COOLERNo
- UNLOCKEDYes
- TDP125W
- WARRANTY 3 Years
Get the best intel processors list at lowest price from us today!
Specifications of INTEL Core i7 10700KF 10th Generation Processor
Essentials | |
Product Collection |
10th Generation Intel® Core™ i7 Processors
|
Code Name |
Products formerly Comet Lake
|
Vertical Segment | Desktop |
Processor Number | i7-10700KF |
Status | Launched |
Lithography | 14 nm |
Use Conditions |
PC/Client/Tablet
|
CPU Specifications | |
# of Cores | 8 |
# of Threads | 16 |
Processor Base Frequency | 3.80 GHz |
Max Turbo Frequency | 5.10 GHz |
Cache |
16 MB Intel® Smart Cache
|
Bus Speed | 8 GT/s |
Intel® Turbo Boost Max Technology 3.0 Frequency ‡ | 5.10 GHz |
Intel® Turbo Boost Technology 2.0 Frequency‡ | 5.00 GHz |
TDP | 125 W |
Configurable TDP-down Frequency | 3.50 GHz |
Configurable TDP-down | 95 W |
Supplemental Information | |
Embedded Options Available | No |
Memory Specifications | |
Max Memory Size (dependent on memory type) | 128 GB |
Memory Types | DDR4-2933 |
Max # of Memory Channels | 2 |
Max Memory Bandwidth | 45.8 GB/s |
ECC Memory Supported ‡ | No |
Expansion Options | |
Scalability | 1S Only |
PCI Express Revision | 3 |
PCI Express Configurations ‡ |
Up to 1x16, 2x8, 1x8+2x4
|
Max # of PCI Express Lanes | 16 |
Package Specifications | |
Sockets Supported | FCLGA1200 |
Max CPU Configuration | 1 |
Thermal Solution Specification | PCG 2015D |
TJUNCTION | 100°C |
Package Size |
37.5mm x 37.5mm
|
Advanced Technologies | |
Intel® Optane™ Memory Supported ‡ | Yes |
Intel® Thermal Velocity Boost | No |
Intel® Turbo Boost Max Technology 3.0 ‡ | Yes |
Intel® Turbo Boost Technology ‡ | 2 |
Intel vPro® Platform Eligibility ‡ | No |
Intel® Hyper-Threading Technology ‡ | Yes |
Intel® Virtualization Technology (VT-x) ‡ | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
Intel® Transactional Synchronization Extensions | No |
Intel® 64 ‡ | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
|
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Identity Protection Technology ‡ | Yes |
Intel® Stable Image Platform Program (SIPP) | No |
Security & Reliability | |
Intel® AES New Instructions | Yes |
Secure Key | Yes |
Intel® Software Guard Extensions (Intel® SGX) |
Yes with Intel® ME
|
Intel® OS Guard | Yes |
Intel® Trusted Execution Technology ‡ | No |
Execute Disable Bit ‡ | Yes |
Intel® Boot Guard | Yes |
Warranty | 3 Years |
Note |
***Features, Price and Specifications are subject to change without notice.
|
