CORE CLOCK
2640 MHz (Reference card: 2610 MHz)
Your one stop destination for all your Computer needs!
2640 MHz (Reference card: 2610 MHz)
NVIDIA Ada Lovelace Architecture
Up to 2X performance and power efficiency
Third-Gen RT Cores
The Ada architecture unleashes the full glory of ray tracing, which simulates how light behaves in the real world. With the power of RTX 40 Series and third-gen RT Cores, you can experience incredibly detailed virtual worlds like never before
DLSS is a revolutionary breakthrough in AI graphics that multiplies performance. Powered by the new fourth-gen Tensor Cores and Optical Flow Accelerator on GeForce RTX 40 Series GPUs, DLSS 3 uses AI to create additional frames and improve image quality.
NVIDIA Reflex and GeForce RTX 40 Series GPUs deliver the lowest latency and best responsiveness for the ultimate competitive advantage. Built to optimize and measure system latency, Reflex provides faster target acquisition, quicker reaction times, and the best aim precision for competitive games.
Discover the RTX AI advantage. Built for the era of AI, GeForce RTX™ GPUs feature specialized AI Tensor Cores that deliver cutting-edge performance and revolutionary capabilities. From enhanced creativity and ultra-efficient productivity to blisteringly fast gaming, the ultimate in AI power on Windows PCs is on RTX.
The WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
Reduce the turbulence of adjacent fans and increase airflow pressure.
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
The large copper plate directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.
Extended heatsink allows air to pass through, providing better heat dissipation.
With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete prote
Ultra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.
Fully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.
GIGABYTE offers the best power supply solutions for your graphics cards. You can choose either the AORUS series or the UD series to power your graphics card.
GIGABYTE CONTROL CENTER is a unified software for all RTX 4070 Ti Super Eagle OC ICE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
Brand | GIGABYTE |
Series | Eagle |
Model | GV-N407TSEAGLEOC ICE-16GD |
Interface | PCI Express 4.0 x16 |
Chipset Manufacturer | NVIDIA |
GPU Series | NVIDIA GeForce RTX 40 Series |
GPU | GeForce RTX 4070 Ti SUPER |
Core Clock | 2640 MHz |
CUDA Cores | 8448 Cores |
Effective Memory Clock | 21000 MHz (21 Gbps) |
Memory Size | 16GB |
Memory Interface | 256-Bit |
Memory Type | GDDR6X |
DirectX | DirectX 12 |
OpenGL | OpenGL 4.6 |
Multi-Monitor Support | 4 |
HDMI | 1 x HDMI |
DisplayPort | 3 x DisplayPort |
Max Resolution | 7680 x 4320 |
Cooler | Triple Fans |
Thermal Design Power | 201W |
Recommended PSU Wattage | 750W |
Power Connector | 1 x 16-Pin |
Form Factor | ATX |
Max GPU Length | 261 mm |
Slot Width | 3 Slots |
