- FANATEC Clubsport Formula V2.5 Steering Wheel
Description
Features of FANATEC Clubsport Formula V2.5 Steering Wheel
FORMULA V2.5. RAISE YOUR GAME.
The ClubSport Steering Wheel Formula V2.5 is the perfect size and shape for all formula-style and single-seater race cars.
PREMIUM MATERIALS
Retaining the shape of the iconic 270 mm ClubSport Formula wheel, the Formula V2.5 uses a 5 mm-thick, solid carbon fibre front plate, aluminium shifter modules, and smooth perforated leather grips.
LOADED WITH FANATEC INNOVATION
Advanced multi-colour LED bars, OLED display, more input options than ever. And now with magnetic shifters as standard.
CRISP SHIFTING
Thanks to the pre-installed, CNC-machined aluminium ClubSport Magnetic Paddle Module, you’ll shift gears with confidence every time. The wheel is packed with 11 buttons, 12-way multi-position switches, thumb encoders, toggle switches; the list goes on. Up to 67 functions of a game can be adjusted directly.
MORE THAN JUST EYE-CATCHING
The spectacular light show is also highly functional. RevLEDs with nine multi-colour LEDs can show motor RPM and optimal shifting point, and the two flag LED bars (FlagLEDs) with three multi-colour LEDs can indicate tyre slip, flag warnings, pit limiter, and more.
ADD F1-STYLE CLUTCH PADDLES
The ClubSport Steering Wheel Formula V2.5 can be upgraded to the Podium Advanced Paddle Module (sold separately), which adds a dual clutch paddle system and two pairs of magnetic paddles with 3 mm-thick carbon fibre plates.
Special Notes
-
In order to operate this product, a compatible Fanatec Wheel Base (not included) is mandatory!
-
This product does not include the Podium Advanced Paddle Module.
Specifications of FANATEC Clubsport Formula V2.5 Steering Wheel
| Model | CRD-9020012-WW |
| Wheel Type | Formula-style steering wheel |
| Wheel Diameter | 270 mm |
| Construction Material | Metal and carbon fibre |
| Front Plate Material | 5 mm solid carbon fibre |
| Carbon Fibre Construction | Approx. 30 layers of unidirectional carbon cloth |
| Grip Material | Genuine smooth leather |
| Grip Feature | Perforated for improved breathability |
| Surface Finish | Rubber-coated surfaces |
| Rubber-Coated Areas | Button framing and thumb encoders |
| Paddle Module | ClubSport Magnetic Paddle Module pre-installed |
| Paddle Plate Material | 3 mm-thick black anodised aluminium |
| Paddle Module Cage | CNC machined aluminium |
| Magnet Type | Neodymium magnets |
| Paddle Upgrade Support | Compatible with Podium Advanced Paddle Module |
| Weight | Approx. 1250 g |
| Buttons | 11 buttons |
| Paddles | Four paddles |
| Switch Type | Ultra-reliable switches |
| Toggle Switches | Two 2-way toggle switches |
| Multi-Position Switches | Two 12-way multi-position switches |
| Encoder Functionality | Supported on multi-position switches |
| FunkySwitch™ | 7-way FunkySwitch™ with directional inputs, push button, and rotary encoder |
| Joystick | Analogue joystick |
| Thumb Encoders | Two thumb encoders |
| Vibration Motors | Two integrated vibration motors |
| Vibration Control | Adjustable through wheel Tuning Menu (SHO) or Fanatec SDK |
| RevLEDs | Nine multi-colour LEDs |
| RevLED Function | Displays motor RPM and optimal shifting point |
| FlagLEDs | Two FlagLEDs with three multi-colour LEDs each |
| FlagLED Function | Indicates tyre slip, flag warnings, pit limiter, and more |
| LED Customization | User-defined via FanaLab |
| Display | 1" 128x64 white OLED display |
| Display Function | Shows telemetry data such as speed or gear |
| Tuning Functions | Integrated tuning functions with OLED display |
| Included Button Caps | Racing-style button caps |
| Quick Release | QR2 Wheel-Side |
| QR2 Installation | Pre-installed |
| Compatiblity | This product is compatible with the following bases (depending on the installed quick release): CSL Elite Wheel Base (QR1 Wheel-Side required) CSL Elite Wheel Base V1.1 (QR1 Wheel-Side required) CSL Elite Wheel Base + - officially licensed for PS4™ (QR1 Wheel-Side required) CSL DD Gran Turismo DD Pro Wheel Base ClubSport Wheel Base V2 (QR1 Wheel-Side required) ClubSport Wheel Base V2.5 (QR1 Wheel-Side required) ClubSport DD ClubSport DD+ PODIUM Wheel Base DD1 PODIUM Wheel Base DD1 PS4™ PODIUM Wheel Base DD2 |
| Platforms | PC: this product is compatible with Windows PC. Xbox: this product is not compatible with Xbox systems. PlayStation: The functionality of this product on PS4 can be limited by the capabilities of the console (subject to firmware/OS changes and developer support). The full functionality can only be guaranteed on PC; this is also game-dependent. PlayStation 5: Check our platform compatibility page for more details. |
| What's Included | ClubSport Steering Wheel Formula V2.5 ClubSport Magnetic Paddle Module with aluminium paddle plates (pre-installed) QR2 Wheel-Side (pre-installed) Racing-style button caps Quick Guide |
| Warranty | 3-Year Warranty |
