- DEEPCOOL SC790 2-In-1 PWM And RGB Hub
Description
Features of DEEPCOOL SC790 2-In-1 PWM And RGB Hub
The DeepCool SC790 2-in-1 PWM & RGB hub provides fan and lighting control for up to 6 total PWM ARGB fans simultaneously while occupying minimal headers on a motherboard.
PWM & ARGB Splitter Hub
The SC790 connects to a 3-pin 5V ARGB header and 4-pin PWM header on a motherboard and extends their signal to connect up to 6 PWM ARGB fans for total synchronization. The included SATA interface ensures stable continuous power for all connected devices.
Specifications of DEEPCOOL SC790 2-In-1 PWM And RGB Hub
| Model Number | R-SC790-BKNSNN-G |
| Product Dimension | 102×60×17 mm |
| Product Color | Black |
| Net Weight | 69g |
| Port Type | ARGB-3Pin & PWM-4 Pin |
| Fan Ports | 6 Ports x 4Pin PWM |
| Length of Fan Connector cable | 24AWG 500 mm |
| Fan Rated Voltage | 12V DC |
| Fan Rated Current | 2.0A(1Port) / Total 4.5A(6Ports) |
| RGB Ports | 6 Ports x 3Pin Addressable RGB |
| Length of ARGB Connector cable | 24 AWG 538mm (Asus Asrock MSI) +50mm (Gigabyte) |
| RGB Rated Voltage | 5V DC |
| RGB Safety Current | 2.0A(1Port) / Total 4.5A(6Ports) |
| Power Connector | SATA Power |
| Power Safety Current | 4.5A Max |
| Mounting Method | Magnetic |
| Warranty | 1 Year |
| Note | *** Features, Price, Specifications are subject to change without notice. |
