- DEEPCOOL CH160 (ITX) Mini Tower Cabinet (White)
Description
Features of DEEPCOOL CH160 (ITX) Mini Tower Cabinet (White)
- Ultimate Portability and Style
- High Airflow panels
- Full sized AIR cooling
- No added GPU latency
- Flexible power options
PREMIUM AIRFLOW:
Mesh panels surround the deepcool cabinet CH160 from numerous sides and create a high-airflow environment; the ability to install up to 172mm tall air coolers also adds to it.
NO ADDED GPU LATENCY:
DEEPCOOL CH160 (ITX) Mini Tower computer cpu case come with 3-slot GPUs up to 305mm can be inserted directly into the motherboard without the aid of a rise cable.
FLEXIBLE POWER OPTIONS:
Whether you choose to go with ATX, SFX, or SFX-L power supplies, the CH160 can support any of them up to 140mm.
ULTIMATE PORTABILITY:
The small size of the CH160, paired with the sturdy carry handle, makes carrying your system painless.
FLEXIBLE DRIVE OPTIONS:
The fan brackets are removable, and the front fan bracket can be utilized to support both an SSD and an HDD drive.
QUALITY OF LIFE IMPROVEMENTS:
With 3 dust filters, 2 USB 3.0, a Type-C, and a hybrid audio port, the CH160 puts everything within arm’s reach.
Specifications of DEEPCOOL CH160 (ITX) Mini Tower Cabinet (White)
Product Dimensions | 336×200×283.5mm(L×W×H) |
Net Weight | 3.3Kg |
Materials | ABS+SPCC+Tempered Glass |
Motherboard Support | Mini-ITX |
Front I/O Ports | USB3.0×2、Audio×1、Gen2 Type-C×1 |
3.5" Drive Bays | 1(2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three) |
2.5" Drive Bays | 1(2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three) |
Expansion Slots | 3 Slots |
Pre-Installed Fans | None |
Fan Support | Front: 1×120 mm(2.5 SSD / 3.5 HDD / Front 120 FAN :Choose one of the three) Top: 2×120mm Rear: 1×120mm |
Radiator Support | None |
CPU Cooler Height Limit | 172mm |
GPU Size Limit | Length: SFX/SFX-L: 305mm / ATX: 230mm Height: 138mm Width: 65mm (3 Slots) |
Power Supply Type | ATX PS2(maximum length: 140mm)/ SFX / SFX-L |
EAN | 6933412774440 |
P/N | R-CH160-WHNGI0-G-1 |
Reviews ( 0 )
Frequently asked questions
1. Is the DEEPCOOL CH160 an ARGB?
The DEEPCOOL CH160 in its basic configuration, doesn't have ARGB lighting. The chassis itself is designed with a simple, clean style. Users can however include ARGB components, like ARGB lights or fans to the case to create the desired effects in lighting. The case can be used with conventional ARGB components, which allows for customizing. So, even though it isn't already equipped, the case is able to accommodate ARGB setups that include user-installed parts.
2. How to remove CH160 front panel?
The removal of front panels from the CH160 front panel usually involves the snap-fit style. To take it off, take the panel away from the chassis, beginning at the bottom. The panel is secured with clips made of plastic, so you must apply consistent pressure to prevent any injury. It is advised to pull straight away from the wall. Avoid excessive force. If you have difficulty getting rid of the panel, referring to the manual of the user for specific directions is helpful. Be sure to take care when handling the front panel to avoid breaking the clips of plastic that attach it onto the chassis.
3. Does DEEPCOOL CH160 have good airflow?
The DEEPCOOL CH160 was built to maximize airflow. It has panels that are ventilated to aid in effective heat loss. The case's design permits sufficient venting and intake of air while ensuring the proper cooling of components. The perforated side panel is designed to allow fresh air to get to the essential components inside the case. The possibility of adding more fans can also increase the flow of air. The slim design does make airflow more crucial and Deepcool has taken this into account.
4. Is a CH160 case good?
It is generally regarded as an excellent ITX case, especially for those looking for a slim and attractive design. It has a variety of options, such as adequate ventilation, support for big GPUs, and an elegant design. Its compact footprint is ideal for small space locations. The reviews often highlight its quality of construction and its ease of use. It's an excellent choice for those seeking a compact PC case with a small form factor. It has a decent number of reviews that are positive.
5. Does the DEEPCOOL CH160 come with fans?
The DEEPCOOL CH160 doesn't typically come with pre-installed cooling fans. This lets users customize their cooling configuration according to their individual requirements and preferences. The user can select the type of fan that will most closely match their needs in terms of performance and aesthetics. This design allows for the flexibility to improve airflow and sound levels. This means that users need to purchase the fans separately in order to complete their setup. The case has the option of mounting fans.
6. Which DEEPCOOL is best?
Best is subjective and is based on the needs of each individual. DEEPCOOL provides a variety of high-quality products. For cooling CPUs the AK620 is often praised due to its outstanding performance. In the case of AIO liquid coolers The LT series is renowned for its dependability and effectiveness. In particular, the CH560 is a favorite due to its spacious airflow and large size. Its FC120 fan is also praised for their low noise and performance. Deepcool produces a variety of products therefore, deciding on the most suitable one is dependent on what the customer is seeking.
7. What is the maximum length of a CH160 GPU?
The DEEPCOOL Ch160 supports GPUs with a maximum size that exceeds 305mm. This allows compatibility with a variety of high-end graphics cards, including high-performance models. It is recommended to verify the exact size of your GPU to ensure it's within the clearance of the case. The design of the case optimizes space, however GPU dimensions remain a crucial aspect to consider for compatibility.
8. What is the price of DEEPCOOL CH160 Argb?
Since the DEEPCOOL CH160 does not contain ARGB it isn't available with a particular ARGB price. The cost of the CH160 is dependent on the seller and location. If you wish to include ARGB it is necessary to consider the price separately ARGB fan or LED strip. Prices for these components may vary significantly. So, the price for an ARGB CH160 set-up will depend on the ARGB components. To determine the current cost going online to find retailers is the most effective method.
9. Are DEEPCOOL fans quiet?
The DEEPCOOL fan is generally designed to run quietly and has many models that focus specifically on noise reduction. The company includes features such as fluid dynamic bearings, as well as optimized fan blade designs that reduce noise. But, the actual noise levels can differ based on the speed of the fan as well as its usage. The FK120 as well as FC120 fans specifically are frequently appreciated by fans for the quietness they provide. In the end, DEEPCOOL aims to provide the right balance between efficiency and quietness with its fan models.
