- COOLER MASTER MWE 650W 80+ White Non Modular ATX 2.0 Power Supply
Description
Feature Of COOLER MASTER MWE 650W 80+ White Non Modular
Cooler Master Power Supply comes with 80 Plus standard certification and is a great choice for most users. Cooler Master MWE 650 White V2 Power Supply offers a simple and reliable way to power your system safely and efficiently. The 80 Plus white efficiency rating, DC-to-DC + LLC circuit design, and a +12V rail along with active PFC and temperature-sensitive HDB fans provide a power supply unit that stays true to its original purpose. The 80 Plus standard 230V EU certification in the MEW White guarantees both a typical efficiency of 85% and is safe and reliable at the same time. The 120mm HDB fans remove the struggle between cooling and noise. The MWE white introduced the solution of using a thermally sensitive 120mm HDB fan.
The fan spins based on the system temperature, constantly adjusting the speeds to keep the PSU running smooth and safe with the minimum amount of noise. DC-to-DC circuit design to convert and deliver power from 12V to 3V and 5V without much ripple noise. The flat black cables of the Cooler Master MWE 650 White V2 Power Supply give aesthetics to the build you are working on. The flat black cables of the Cooler Master MWE 650W Power Supply White are more flexible and discrete making them easier to implement in the system. The Cooler Master MWE 650 White V2 Power Supply comes with all the necessary power protections like Over Voltage Protection and Over Power Protection, Over Temperature Protection, and Short Circuit Protection.
The MWE White offers a simple, reliable way to power your system safely and efficiently at a low cost. The 80 PLUS White efficiency rating, DC-to-DC LLC circuit design, single 12V rail, active PFC, and temperature sensitive HDB fan offer a power supply unit that stays true to its original purpose. This PSU will handle all your core computing needs with none of the hassles or challenges of additional specialty features, software synchronization, or other bells and whistles. Just plug it into your system and get to work. For a great core computing experience, you can’t go wrong with the MWE White.
80 Plus Standard 230V EU Certified
It’s important to understand what efficiency is and what the ratings actually mean. The efficiency rating indicates how much power is retained and/or lost when transferring it from the wall to your components. It does not indicate the overall quality of the PSU. A PSU doesn’t need an 80 PLUS Gold rating to be safe and reliable. And a PSU with an 80 PLUS Gold rating isn’t necessarily either of those things. The MWE White guarantees a typical efficiency of 85% while being both safe and reliable. Cooler Master now reports Cybenetics noise and efficiency ratings for current power supply units where applicable.
120mm HDB fan
The constant struggle between cooling and noise is as old as the consumer PC industry itself. Keeping your components cool without having to hear about it while you work is still one of the greatest challenges for all fan based cooling technologies. The MWE White’s solution to this problem is a thermally sensitive 120mm HDB fan. It spins based on the system’s temperature, constantly adjusting to keep your PSU running smoothly and safely with the minimum amount of noise required.
Single 12V rail
Getting power from the wall to the PSU and then to your components is a tricky situation. The power comes in one voltage level, but your components need a different one. That power has to first be transferred to/through a converter in order to make it safe for your parts to use without overloading. The lines/rails used to initially move power from the wall to the converter need to be reliable and consistent to ensure your system’s overall performance. That’s why the MWE White only uses one 12V rail for this process. This way all the components in your system are constantly fed the same power from the same source in order to guarantee consistency between all connections.
DC-TO-DC Circuit Design
Power comes in multiple voltage levels. The wall delivers power in one voltage level but your components each need a specific voltage to operate properly. The process of converting raw power from the wall to the multiple voltage levels your components need requires special components to complete this process quickly, efficiently, and safely. The MWE White’s DC-to-DC LLC technology was painstakingly crafted to accomplish this goal. The Dual Forward circuit layout has been designed to convert 12V power to 3V and 5V levels with minimal ripple noise, 80 PLUS efficiency, and reduced risk to your connected components.
Get the best 80 Plus White psu power supply price from us today!
Specifications Of COOLER MASTER MWE 650W 80+ White Non Modular
Product Name | MasterWatt White 650 | |
Model Number | MPE-6501-ACABW | |
Type | ||
PFC | Active PFC | |
Input Voltage | 200-240Vac | |
Input Current | 5 A | |
Input Frequency | 50-60 Hz | |
Dimensions (LxBxH) | 140 x 150 x 86 mm | |
Fan Size | 120 mm | |
Fan Bearing | HDB | |
Fan Speed | 2400 RPM | |
Power Good Signal | 100-500 ms | |
Hold Up Time | >14ms at 100% full load@230Vac | |
MTBF | 100,000 Hours | |
Operating Temperature | 40°C | |
MB 24 Pin | 1 | |
CPU 12V 4 4 Pin | 1 | |
SATA | 6 | |
Peripheral 4 Pin | 3 | |
PCI-e 6 2 Pin | 4 | |
Warranty | 5 Years | |
Note | ***Features, Price and Specifications are subject to change without notice. |
