- ASUS TUF Gaming Radeon RX 7900 XT OC Edition 20GB AMD Graphic Card
Description
Features of ASUS TUF Gaming Radeon RX 7900 XT OC Edition 20GB
ASUS TUF Gaming Radeon™ RX 7900 XT OC Edition 20GB GDDR6 graphic card optimized inside and out for lower temps and durability.
- Axial-tech fans scaled up to deliver 14% more airflow
- Dual ball fan bearings last up to twice as long as conventional designs
- Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable
- Metal Exoskeleton adds structural rigidity and vents to increase heat dissipation
- Auto-Extreme precision automated manufacturing for higher reliability
- GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring
FLYIN’ TUF
The AMD RDNA™ 3 Architecture elevated by buffed cooling and power delivery to effortlessly churn out frames at 4K resolution and beyond, and backed with an arsenal of rugged reinforcements to cover your six. Lock, load, and dominate with the TUF Gaming AMD Radeon™ RX 7900 XT.
AXIAL-TECH UPGRADES
Air Superiority
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 14% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
NEW DIRECTION
Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 55 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 60 Celsius, referencing a speed curve that balances performance and acoustics for work or play.
3.63-SLOT DESIGN
Phase That Blaze
A generously sized heatsink efficiently soaks up heat from the AMD Radeon™ RX 7900 XT GPU, allowing it to be whisked away by the three Axial-tech fans.
MILITARY-GRADE 20K CAPACITORS
Resilient Squadron
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.
METAL EXOSKELETON
Suit up
A diecast frame, aluminum shroud, and backplate prevent PCB flex and feature large vents to further increase heat dissipation.
Auto−Extreme Technology
Reliability Boost
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
AURA SYNC
Light 'em up!
Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.
Software Suite
Harness the hardware
Hardware and software come together to let you fully customize your experience and get the most out of your graphics card. GPU Tweak III allows for hardware tweaking and monitoring, and QuantumCloud utilizes your spare GPU computing power to generate passive income.
The Most Advanced Graphics For Gamers
Experience unprecedented performance, visuals, and efficiency at 4K and beyond with AMD Radeon™ RX 7000 Series graphics cards, the world's first gaming GPUs powered by AMD RDNA™ 3 chiplet technology. Immerse yourself in breathtaking visuals with the pinpoint color accuracy of AMD Radiance Display™ Engine and boost frame rates with AMD FidelityFX™ Super Resolution and AMD Radeon™ Super Resolution upscaling technologies. To unlock even more performance, combine AMD Radeon™ RX 7000 Series graphics and compatible AMD Ryzen™ processors to activate AMD smart technologies.
Breakthrough Performance
AMD Radeon™ RX 7000 Series graphics cards set a new standard for ultra-enthusiast class gaming performance. Featuring advanced AMD RDNA™ 3 compute units, blazing fast clock speeds, and chiplet technology to enable fluid, high-refresh rate gaming experiences. Breakthrough new levels of performance with up to 24GB of GDDR6 memory and 2nd generation AMD Infinity Cache™ to deliver an incredible experience at 4K and beyond.
AMD FidelityFX™ Super Resolution technology
AMD FidelityFX™ Super Resolution technology, or FSR, uses cutting-edge super-optimized spatial upscaling technology to generate super high-quality edges and distinctive pixel detail. With FSR, turn on the latest features and settings in your games while maintaining an acceptable framerate.
Specifications of ASUS TUF Gaming Radeon RX 7900 XT OC Edition 20GB
Model | |
Brand | ASUS |
Model | TUF-RX7900XT-O20G-GAMING |
Form Factor | Radeon™ RX 7900 XT OC Edition |
Interface | |
Interface | PCI Express 4.0 |
Chipset | |
GPU | AMD Radeon RX 7900 XT |
Core clock | OC mode : up to 2535 MHz (Boost Clock)/up to 2175 MHz (Game Clock), Default mode : up to 2500 MHz (Boost Clock)/up to 2130 MHz (Game Clock) |
Memory | |
Memory Clock | 20 Gbps |
Memory Size | 20GB |
Memory Interface | 320-bit |
Memory Type | GDDR6 |
3D API | |
OpenGL | OpenGL 4.6 |
Ports | |
HDMI | Yes x 1 (Native HDMI 2.1) |
DisplayPort | 3 x DisplayPort |
General | |
Max Resolution | 7680x4320 |
Cooler | Triple Fan |
HDCP Ready | 2.3 |
Power Connector | 8-pin x 3 |
