- TPLink Archer AX20 AX1800 Dual-Band Wi-Fi 6 Router
Description
Features of TPLink Archer AX20 AX1800 Dual-Band Wi-Fi 6 Router
Dual-Band Wi-Fi 6 –
Equipped with the latest wireless technology, Wi-Fi 6, for faster speeds, greater capacity, and reduced network congestion.
Next-Gen 1.8 Gbps Speeds –
Enjoy smooth streaming, downloading, and gaming all without buffering with Wi-Fi speeds of 1.8 Gbps.†
Connect More Devices –
Wi-Fi 6 technology communicates more data to more devices using revolutionary OFDMA technology while simultaneously reducing lag.△§
Extensive Coverage –
Beamforming, independent FEM, and four antennas combine to deliver focused reception to devices far away.
OneMesh Compatible –
Use with OneMesh extenders to get whole-home coverage and enjoy smooth roaming between signals.
Increased Battery Life –
Target Wake Time technology reduces your devices' power consumption to extend their battery life.‡
USB Easy Sharing –
A USB 2.0 Port enables easy file sharing within your network or building private Cloud Storage.
Easy Setup –
Set up your router in minutes with the powerful TP-Link Tether App AX20 AX1800
Backward Compatible –
Supports all previous 802.11 standards and all Wi-Fi devices.
Specifications of TPLink Archer AX20 AX1800 Dual-Band Wi-Fi 6 Router
WIRELESS | |
Standards |
Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
WiFi Speeds |
AX1800 5 GHz: 1201 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax) |
WiFi Range |
3 Bedroom Houses4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming High-Power FEM |
WiFi Capacity |
HighDual-Band Allocate devices to different bands for optimal performance OFDMA Airtime Fairness 4 Streams |
Working Modes |
Router Mode Access Point Mode |
HARDWARE | |
Processor | 1.5 GHz Quad-Core CPU |
Ethernet Ports |
1× Gigabit WAN Port 4× Gigabit LAN Ports |
USB Support |
1× USB 2.0 Port
Supported Partition Formats: Supported Functions: |
Buttons |
WPS/Wi-Fi Button Power On/Off Button LED On/Off Button Reset Button |
Power | 12 V ⎓ 1.5 A |
SECURITY | |
WiFi Encryption |
WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x) |
Network Security |
SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
Guest Network |
1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
VPN Server |
OpenVPN PPTP |
SOFTWARE | |
Protocols |
IPv4 IPv6 |
OneMesh™ |
OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products. Learn More> All OneMesh Products> |
Parental Controls |
URL Filtering Time Controls |
WAN Types |
Dynamic IP Static IP PPPoE PPTP L2TP |
Quality of Service | QoS by Device |
Cloud Service |
Auto Firmware Upgrade OTA Firmware Upgrade TP-Link ID DDNS |
NAT Forwarding |
Port Forwarding Port Triggering DMZ UPnP |
IPTV |
IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP |
Address Reservation DHCP Client List Server |
DDNS |
TP-Link NO-IP DynDNS |
Management | Tether App |
OTHER | |
System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
Certifications | FCC, CE, RoHS |
Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
TEST DATA | |
WiFi Transmission Power |
CE: <20dBm(2.4 GHz) <23dBm(5.15 GHz~5.25 GHz) FCC: <30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
WiFi Reception Sensitivity |
5 GHz: 11a 6Mbps:-97dBm 11a 54Mbps:-79dBm 11ac VHT20_MCS0:-96dBm 11ac VHT20_MCS11:-66dBm 11ac VHT40_MCS0:-94dBm 11ac VHT40_MCS11:-63dBm 11ac VHT80_MCS0:-91dBm 11ac VHT80_MCS11:-60dBm 11ax HE20_MCS0:-95dBm 11ax HE20_MCS11:-63dBm 11ax HE40_MCS0:-92dBm 11ax HE40_MCS11:-60dBm 11ax HE80_MCS0:-89dBm 11ax HE80_MCS11:-58dBm 2.4 GHz: 11g 6Mbps:-97dBm 11n HT20_MCS0:-97dBm 11n HT20_MCS7:-78dBm 11n HT40_MCS0:-95dBm 11n HT40_MCS7:-75dBm 11ac VHT20_MCS0:-96dBm 11ac VHT20_MCS11:-67dBm 11ac VHT40_MCS0:-94dBm 11ac VHT40_MCS11:-64dBm 11ax HE20_MCS0:-96dBm 11ax HE20_MCS11:-64dBm 11ax HE40_MCS0:-93dBm 11ax HE40_MCS11:-61dBm |
PHYSICAL | |
Dimensions (W×D×H) |
10.2 × 5.3 ×1.5 in (260.2 × 135.0 × 38.6 mm) |
Package Contents |
Wi-Fi Router Archer AX20 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
