- ANTEC NE550M 550W 80+ Bronze Semi Modular ATX 2.0 Power Supply
Description
Features of ANTEC NE550M
Antec NE550M 550W 80 Plus Bronze PSU is engineered to meet the power demands of midrange systems. Antec NE550M 550W 80 Plus Bronze PSU series boasts unparalleled stability and 80 PLUSBronze certified efficiency, thanks to its next level capacitors and Active PFC. The PSU comes with a custom135MM FDB FAN. The fan provides high airflow with the durability and longevity that is a signature of Antec quality.
The Antec NE550M comes with a Semi-modular cable interface to keep your build clutter-free and clean. This PSU guarantees 550W of continuous power draw. The 80 PLUS bronze certification-Up to 92% efficient, to reduce your electricity bill. The PSU comes withCircuitShield™-Full suite of industrial-grade protections: OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO.
High-Quality capacitors achieve unprecedented tight voltage regulation & low ripple & noise to maximize your system’s performance. ATX12V 2.4-Engineered according to the newest PSU guideline and compatible with the latest CPU generation.
HCG Extreme delivers non-stop industrial class performance for high-end computer systems at up to 50°C ambient. The PSU has an Input Voltage of 100-240 VAC ±10%, Input Current of 13A-6.5A, Input Frequency Range of 50Hz-60Hz, Active PFC (>0.9 typical).
High-Efficiency Power Supply
Get economical power today with the NeoECO Modular, Antec's high-efficiency power supply solution. Featuring 80 PLUS® BRONZE certification, a quiet 120 mm fan, Japanese capacitors and Universal Input with Active Power Factor Correction, NeoECO Modular gives you a cooler, quieter system, all powered by Continuous Power.
80 PLUS Bronze Certified
Up to 88% efficient, to reduce your electricity bill.
Japanese Heavy-duty Caps
Japanese High-performance capacitors ensure tightest DC stability and regulation.
Advanced Hybrid Cable Management
Improves airflow and reduces clutter.
120mm silent Fan
Whisper-quiet high-quality silent fan with long lifetime. stealth flat cable. For easier & better cable management.
Efficiency Load
AC INPUT: 100 - 240VAC
Specifications of ANTEC NE550M
TECHNICAL SPECIFICATIONS | |
Model | NE 550M |
Series | NeoECO Modular |
Part Number | 0-761345-10587-3 |
Type | Power Supply |
Compliant with | ATX12V 2.4 & EPS12V 2.92 |
Efficiency | 80 PLUS® BRONZE |
Wattage | 550W |
OTHER SPECIFICATIONS | |
Input Voltage | 100VAC - 240VAC ~ ±10% (Active PFC) |
Input Current | 8A - 4A |
Input Frequency | 47Hz - 63Hz |
PFC | Active |
Operating Temperature | 0⁰C - 40⁰C |
MTBF | ≥ 100,000 hours |
PROTECTIONS | CircuitShield™ |
Safety Certificates | CE, TÜV, CB, EAC, FCC, cTUVus, RCM |
DIMENSIONS & WEIGHT | |
Dimensions | 3.4" x 5.9" x 5.5" (HxWxD) / 86 mm x 150 mm x 140 mm HxWxD |
Net Weight | 3.2lbs / 1.5 kg |
Unit Carton | 8.3" x 9.1" x 4.3" (HxWxD) / 210 mm x 230 mm x 110 mm HxWxD |
Warranty | 3 Years |
Note | ***Features, Price and Specifications are subject to change without notice. |
