- ADDLINK S70 256GB M.2 NVME Gen4 Internal Solid State Drive ( SSD )
Description
Feature of ADDLINK S70 256GB M.2 NVME Gen4
S70 Lite GEN3X4 NVMe
ADDLINK S70 Lite SSD is perfect for heavy-duty applications, such as digital audio/video production, gaming and professionThe Addlink S70 Lite Gen3x4 SSD is the go-to choose for those looking to upgrade their Chromebooks, laptops, and Ultrabooks. With its low power consumption and a slim design under 2.25mm in height (attributed to its single-sided flash), users can be assured it won't interfere with their mobile device mechanics. Delivering read speeds of up to 3500MB/s, the S70 Lite is ideal for laptop aficionados, and professionals.al use, that has no room for system lags or any kinds of slowdowns. S70 is powered by 3D NAND flash memory, which gives you not only fast transfer speeds but unbelievable reliability.
Gen3x4 Speeds Rivaling PCIe Gen4x4
The addlink S70 lite employs the PCIe Gen3x4 1.4 interface and boasts read/write speeds of up to 3500/2600MB/s. This performance closely rivals that of PCIe Gen4x4 SSD. It’s worth noting that the S70 Lite is seven times faster than SATA III SSDs and is compatible with both PCIe 4.0 and PCIe 5.0 NVMe interfaces.
Balancing Speed and Power The New Era of SSDs
The S70 Lite is a DRAM-less SSD, resulting in half the power consumption compared to other Gen3x4 SSDs with DRAM cache. Despite this, it doesn't compromise on speed, achieving up to 3500Mb/s, which closely rivals the performance of PCIe Gen4x4. Unlike Gen4 SSDs, which are known for their higher heat output, the S70 Gen3x4 SSD operates within a temperature range of 40-60 degrees Celsius, ensuring your laptop stays cool during use.
Top SSD Tech for Contemporary Laptops
The drive uses SLC caching and a host memory buffer (HMB) to boost the S70 Lite SSD's performance. Made with 3D NAND Flash, it employs LDPC ECC, Wear Leveling, Bad Block Management, and Over-Provisioning to ensure data accuracy and longevity. Compatible with Intel and AMD system, it integrates into most PCs and laptops. Backed by a 5-year warranty, it promises durability and value.
Specifications of ADDLINK S70 256GB M.2 NVME Gen4
Model | AD256GBS70M2P |
Capacity | 256GB |
DRAM Cache | DDR3L / DDR4L(High Capacity) |
Dimensions | 80(L)x22(W)x3.5(Max.H) mm, 8.2g |
Interface | NVMe GEN3x4 1.3 |
Form Factor | M.2 2280 |
Seq. Read/Write (MB/s) |
3000/1000 According to addlink inside test by CrystalDiskMark software, read/write speed depend on the device, interface, usage and other factors so that actual performance may be lower. |
4K Random Read/Write (IOPS) | 220K/320K |
Operating Temp. | 0°C ~ 70°C |
Storage Temp. | -40°C ~ 85°C |
Power Consumption R/W | 5.1W/3.1W |
MTBF | 1.8 Million Hours |
TBW | 400 TBW |
Support Functions | TRIMM DEVSLP, Garbage Collection, ECC, S.M.A.R.T, SLC Caching, Wear Leveling, Bad Block management, Over-Provision, RAID Protection |
Operating System | Microsoft Windows 7 (additional driver required) Microsoft Windows 8 (additional driver required) Microsoft Windows 10, Linux Kernel 2.6.31 or later |
Warranty | 5 Years or 400 TBW |
NOTE | ***Features, Price and Specifications are subject to change without notice. |
